21/11/2024

Lacing tape 500 m x 1.52 mm, PET, black
Art.-No. 174-00024 | LTHT2E4BK-PET-BK |  Details

Lacing cord LTHT2E4BK.

    • High tensile strength
    • Vinyl chloride surface finishing provides good abrasion resistance
    Add to watchlist
    Downloads Datasheet
    Colour Black (BK)
    Fixation Method Others
    Identification Plate Position none
    Material Polyester (PET)
    PART DESCRIPTION LTHT2E4BK-PET-BK
    Pack Cont. 500m
    Package Content packed in reel
    Product Family Lacing tape LTHT2E4BK
    Product Group Lacing tape made of polyester
    Releasable Closure (Yes/No) Yes
    Short Description Lacing tape 500 m x 1.52 mm, PET, black
    Type LTHT2E4BK
    Variant Endless
    Length (L) 500m
    Min.Tensile Strength 113N
    Thickness (T) 0.3mm
    Thickness (T) 0.27-0.43mm
    Weight 0.6g/m
    Weight/Unit 0.0006kg
    Width (W) 1.52mm
    Width (W) max. 1.67mm
    Width (W) min. 1.37mm
    Curing Temperature -67 °C to +177 °C
    ELV compliant (Article 4 - 2) YES
    Finish E = Vinyl
    Hazardous Goods No
    Lacing Shape Flat, braided
    Operating Temperature -67 °C to +177 °C
    ROHS compliant Yes
    Specifications
    Specifications A-A-52081, NSA8420
    Surface Finishing Shortcut E
    Country of Origin FR
    Customs Number 58081000
    GTIN-13 / EAN 4031026437439
    Packaging 1 - Height (m) 0.26m
    Packaging 1 - Length (m) 0.51m
    Packaging 1 - Qty 500
    Packaging 1 - Type reel
    Packaging 1 - Volume (m³) 0.02519m³
    Packaging 1 - Weight (kg) 0.3kg
    Packaging 1 - Width (m) 0.19m
    Packaging 3 - Height (m) 0.145m
    Packaging 3 - Length (m) 0.38m
    Packaging 3 - Qty 9000
    Packaging 3 - Type box
    Packaging 3 - Volume (m³) 0.0209m³
    Packaging 3 - Weight (kg) 5.76kg
    Packaging 3 - Width (m) 0.38m
    Packaging 4 - Height (m) 1.304m
    Packaging 4 - Length (m) 1.2m
    Packaging 4 - Qty 432000
    Packaging 4 - Type pallet
    Packaging 4 - Volume (m³) 1.252m³
    Packaging 4 - Weight (kg) 297.48kg
    Packaging 4 - Width (m) 0.8m
    Reel Length 500m
    ETIM 7.0 Key EC000046
    ETIM 8.0 Key EC000046
    ETIM 9.0 Key EC000046
