Mechanical connector, 16 - 95mm², ⌀16mm, L=55mm, metal
Art.-No. 435-01504 | Mechanical connector 1695-ST-ML |  Details

    This product is not available anymore.
    • For connecting different conductor cross-sections
    • Suitable for aluminium and copper conductors
    • Tin-plated connector body with barrier and shear-off bolts
    Add to watchlist
    Downloads
    Application Galvanised mechanical connector provided with barrier and shear-off bolts. Suitable for stranded and solid aluminium and copper conductors in all kind of cable accessories. They also comply with DIN 4740 requirements for shrinking technology.
    Colour Zinc-plated Metal (BV)
    Material Steel (ST)
    PART DESCRIPTION Mechanical connector 1695-ST-ML
    Pack Cont. 1pc.
    Package Content packed in pcs.
    Product Family Mechanical connector, tin-plated, with barrier and shear-off bolts for AI and CU conductors
    Product Group Connectors
    Short Description Mechanical connector 1695 ST ML
    Type Mechanical connector 1695
    Conductor Size Range mm² 16 - 95mm²
    Diameter (D) 16mm
    Length (L) 55mm
    Nut Size (NS) 8mm
    Weight/Unit 0.074kg
    ELV compliant (Article 4 - 2) YES
    Hazardous Goods No
    ROHS compliant Yes
    Specifications
    Voltage Range up to 15kV
    Country of Origin DE
    Customs Number 85369010
    GTIN-13 / EAN 4250596412756
    Packaging 1 - Height (m) 0.022m
    Packaging 1 - Length (m) 0.056m
    Packaging 1 - Qty 1
    Packaging 1 - Type pack
    Packaging 1 - Volume (m³) 0.00005m³
    Packaging 1 - Weight (kg) 0.074kg
    Packaging 1 - Width (m) 0.042m
    ETIM 7.0 Key EC001063
    ETIM 8.0 Key EC001063
    ETIM 9.0 Key EC001063
