25/12/2024

Connector clip for connector, black, 2000pcs.
Art.-No. 151-03448 | 23MM17MMCCADPT-PA66HIRHSUV-BK |  Details

Adapter to change from USCAR 23 mm clip to USCAR 17 mm Clip.

    Add to watchlist
    Downloads Datasheet
    Colour Black (BK)
    Material Polyamide 6.6, high impact modified, heat and UV-stabilised (PA66HIRHSUV)
    PART DESCRIPTION 23MM17MMCCADPT-PA66HIRHSUV-BK
    Pack Cont. 2000pcs.
    Package Content packed in carton
    Type 23MM17MMCCADPT
    Height (H) 13.2mm
    Length (L) 29.1mm
    Width (W) 20.5mm
    Width (W2) 17.2mm
    CE Certification No
    Flammability UL 94 HB
    Halogen-free Yes
    Operating Temperature -40 °C to +105 °C
    ROHS compliant Yes
    Specifications
    UL Recognized (US and Canada) No
    UV-Stabilised Yes
    Country of Origin MX
    GTIN-13 / EAN 4031026663715
    Packaging 3 - Height (m) 0.136525m
    Packaging 3 - Length (m) 0.5191125m
    Packaging 3 - Type box
    Packaging 3 - Volume (m³) 0.0217m³
    Packaging 3 - Width (m) 0.3063875m
    ETIM 7.0 Key EC000127
    ETIM 8.0 Key EC000127
    ETIM 9.0 Key EC000127
    UNSPSC Key 39121702
