19/11/2024

Fixing element 35x10 mm, high impact modified, heat stabilised, black
Art.-No. 151-01078 | AHC223FT6LG-PA66HIRHS-BK |  Details

    Package size
    Add to watchlist
    Downloads Datasheet
    Colour Black (BK)
    Key product features lockable, removable
    Material Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
    PART DESCRIPTION AHC223FT6LG-PA66HIRHS-BK
    Pack Cont. 1300pcs.
    Package Content packed in bulk
    Short Description Fixing element 35x10 mm, high impact modified, heat stabilised, black
    Type AHC223FT6LG
    Bundle Diameter max (metric) 23.0mm
    Bundle ∅ 20.0-23.0mm
    Bundle ∅ min. 20.0mm
    Disc ∅ 20.0mm
    Length (L) 35.0mm
    Panel Thickness max. 0.7 - 4.0mm
    Weight/Unit 0.002995kg
    Width (W) 10.0mm
    for Hole ∅ (FH) 6.4 - 7.0 mm
    for Panel Thickness min - max 0.7 - 4 mm
    ELV compliant (Article 4 - 2) YES
    Hazardous Goods No
    ROHS compliant Yes
    Specifications
    Country of Origin FR
    Customs Number 39269097
    GTIN-13 / EAN 4031026501161
    Packaging 1 - Height (m) 0.14m
    Packaging 1 - Length (m) 0.59m
    Packaging 1 - Qty 1300
    Packaging 1 - Type bag
    Packaging 1 - Volume (m³) 0.03221m³
    Packaging 1 - Weight (kg) 3.893501kg
    Packaging 1 - Width (m) 0.39m
    Packaging 3 - Height (m) 0.25m
    Packaging 3 - Length (m) 0.6m
    Packaging 3 - Qty 1300
    Packaging 3 - Type box
    Packaging 3 - Volume (m³) 0.06m³
    Packaging 3 - Weight (kg) 4.643501kg
    Packaging 3 - Width (m) 0.4m
    Packaging 4 - Height (m) 1.144m
    Packaging 4 - Length (m) 1.2m
    Packaging 4 - Qty 20800
    Packaging 4 - Type pallet
    Packaging 4 - Volume (m³) 1.098m³
    Packaging 4 - Weight (kg) 95.296kg
    Packaging 4 - Width (m) 0.8m
    ETIM 7.0 Key EC000464
    ETIM 8.0 Key EC000464
    ETIM 9.0 Key EC000464
    UNSPSC Key 39121702
