Bundling clip for stud, L=60.0mm, SO=20.0mm, black, 1000pcs.
Art.-No. 102-68368
| ATSBC60SOC20SBS5-PA66HIRHS-BK
|
Details
- Optimized for use Automatic Cable Tying Systems
- Easy to apply
- Fixing elements can be used with the Autotool CPK hybrid and Autotool Systems 3080 / ATS flex
- Special designed for automatisation
More products in this product group:
| Application | This fixing element with T5 stud and bundling bar is special designed for automatisation processes. They can be used with the Autotool CPK hybrid and Autotool Systems 3080 / ATS flex but also with other cable ties or tapes. |
| Colour | Black (BK) |
| Description | Bundling clip, for stud, Polyamide 6.6, high impact modified, heat stabilised, black |
| Fixation Method | Weld Stud Fixing |
| Key product features | products for automatic tools |
| Material | Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS) |
| PART DESCRIPTION | ATSBC60SOC20SBS5-PA66HIRHS-BK |
| Pack Cont. | 1000pcs. |
| Package Content packed in | bag |
| Product Family | Bundling clip for stud |
| Product Group | Bundling clip for stud |
| Short Description | Bundling clip, for stud, Polyamide 6.6, high impact modified, heat stabilised, black |
| Type | ATSBC60SOC20SBS5 |
Download
|
|
|
| Country of Origin | PL |
| Customs Number | 39269097 |
| GTIN-13 / EAN | 4031026741062 |
| Packaging 1 - Height (m) | 0.07m |
| Packaging 1 - Length (m) | 0.395m |
| Packaging 1 - Qty | 1000 |
| Packaging 1 - Type | bag |
| Packaging 1 - Volume (m³) | 0.01244m³ |
| Packaging 1 - Weight (kg) | 1.529135kg |
| Packaging 1 - Width (m) | 0.45m |
| Packaging 3 - Height (m) | 0.368m |
| Packaging 3 - Length (m) | 0.584m |
| Packaging 3 - Qty | 8000 |
| Packaging 3 - Type | box |
| Packaging 3 - Volume (m³) | 0.083m³ |
| Packaging 3 - Weight (kg) | 13.05308kg |
| Packaging 3 - Width (m) | 0.386m |
| Packaging 4 - Height (m) | 1.248m |
| Packaging 4 - Length (m) | 1.2m |
| Packaging 4 - Qty | 96000 |
| Packaging 4 - Type | pallet |
| Packaging 4 - Volume (m³) | 1.198m³ |
| Packaging 4 - Weight (kg) | 177.624kg |
| Packaging 4 - Width (m) | 0.8m |
