Connector clip for connector/for hole (oval), black, 5000pcs.
Art.-No. 151-02898 | CC20SFT712-PA66HIRHS-BK |  Details

    • Connector easily installed by simply pushing into place
    • Connection can be released (non-destructive)
    • Easy to assemble without the need for a tool
    • Oval connectors offer twist protection
    Add to watchlist
    Downloads Datasheet
    Application The connector clip used here have been desgined for electronic cables and cable sets used in the automotive industry.
    Colour Black (BK)
    Material Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
    PART DESCRIPTION CC20SFT712-PA66HIRHS-BK
    Pack Cont. 5000pcs.
    Package Content packed in carton
    Product Family connector clip for oval holes
    Product Group 1-piece connector clip for oval holes
    Type CC20SFT712
    Height (H) 14.7mm
    Length (L) 23.0mm
    Panel Thickness max. 0.7 - 2.0mm
    Width (W) 16.0mm
    for Hole ∅ (FH) 7.0 x 12.0 mm
    for Panel Thickness min - max 0.7 - 2 mm
    Country of Origin CN
    GTIN-13 / EAN 4031026622675
    ETIM 7.0 Key EC000127
    ETIM 8.0 Key EC000127
    ETIM 9.0 Key EC000127
    UNSPSC Key 39121702
