22/11/2024

Connector clip, black, 1000Bag
Art.-No. 151-02792 | CC5AHOVAL7X12CLIP-PA66HIRHSUV-BK |  Details

    Add to watchlist
    Downloads Datasheet
    Colour Black (BK)
    Material Polyamide 6.6, high impact modified, heat and UV-stabilised (PA66HIRHSUV)
    PART DESCRIPTION CC5AHOVAL7X12CLIP-PA66HIRHSUV-BK
    Pack Cont. 1000Bag
    Package Content packed in bag
    Type CC5AHOVAL7X12CLIP
    Height (H) 16.6mm
    Length (L) 32.0mm
    Weight/Unit 0.00102kg
    Width (W) 16.0mm
    for Hole ∅ (FH) 7.0 x 12.0 mm
    for Panel Thickness min - max 1.4 - 1.6 mm
    ELV compliant (Article 4 - 2) YES
    Hazardous Goods No
    ROHS compliant Yes
    Specifications
    UL Listed (US and Canada) No
    UL Listed (US and Canada) No
    UL Recognized (US and Canada) No
    UL Recognized (US and Canada) No
    UV-Stabilised Yes
    Country of Origin MX
    Customs Number 39269097
    GTIN-13 / EAN 4031026702384
    Packaging 1 - Height (m) 0.07m
    Packaging 1 - Length (m) 0.429m
    Packaging 1 - Qty 1200
    Packaging 1 - Type bag
    Packaging 1 - Volume (m³) 0.00778m³
    Packaging 1 - Weight (kg) 1.244kg
    Packaging 1 - Width (m) 0.259m
    Packaging 3 - Height (m) 0.1508125m
    Packaging 3 - Length (m) 0.4365625m
    Packaging 3 - Qty 1200
    Packaging 3 - Type box
    Packaging 3 - Volume (m³) 0.0176m³
    Packaging 3 - Weight (kg) 1.584kg
    Packaging 3 - Width (m) 0.2667m
    Packaging 4 - Height (m) 1.201m
    Packaging 4 - Length (m) 1.2m
    Packaging 4 - Qty 50400
    Packaging 4 - Type pallet
    Packaging 4 - Volume (m³) 1.153m³
    Packaging 4 - Weight (kg) 87.528kg
    Packaging 4 - Width (m) 0.8m
    ETIM 7.0 Key EC000127
    ETIM 8.0 Key EC000127
    ETIM 9.0 Key EC000127
    UNSPSC Key 39121702
