Connector clip, black, 2000pcs.
Art.-No. 133-02868
| CCFT6.35HTS6.25-PP-BK
|
Details
- Connector easily installed by simply pushing into place
- Connection can be released (non-destructive)
- One fir tree foot part can be used for a variety of panel thicknesses
- Disc covers the hole to prevent dirt and water gaining access
- For twist protection: Variants with additional stick or for oval holes
| Application | The connector clips used here have been designed for electronic cables and cable sets used in the automotive industry. |
| Colour | Black (BK) |
| Fixation Method | Fir Tree |
| Material | Polypropylene (PP) |
| PART DESCRIPTION | CCFT6.35HTS6.25-PP-BK |
| Pack Cont. | 2000pcs. |
| Package Content packed in | carton |
| Type | CCFT6.35HTS6.25 |
Download
| CE Certification | No |
| CSA Certified | No |
| ELV compliant (Article 4 - 2) | YES |
| Hazardous Goods | No |
| Operating Temperature | -40 °C to +115 °C |
| ROHS compliant | Yes |
| Specifications |
|
| UL Listed (US and Canada) | No |
| UL Listed (US and Canada) | No |
| UL Recognized (US and Canada) | No |
| UL Recognized (US and Canada) | No |
| UV-Stabilised | Yes |
|
|
|
| Country of Origin | MX |
| Customs Number | 39269097 |
| GTIN-13 / EAN | 4031026582368 |
| Packaging 3 - Height (m) | 0.1603502m |
| Packaging 3 - Length (m) | 0.5159502m |
| Packaging 3 - Qty | 2000 |
| Packaging 3 - Type | box |
| Packaging 3 - Volume (m³) | 0.0282m³ |
| Packaging 3 - Weight (kg) | 5.11kg |
| Packaging 3 - Width (m) | 0.3413252m |
| Packaging 4 - Height (m) | 1.182m |
| Packaging 4 - Length (m) | 1.2m |
| Packaging 4 - Qty | 48000 |
| Packaging 4 - Type | pallet |
| Packaging 4 - Volume (m³) | 1.135m³ |
| Packaging 4 - Weight (kg) | 143.64kg |
| Packaging 4 - Width (m) | 0.8m |
