22/02/2025

Connector clip for hole (round), black, 1000pcs.
Art.-No. 151-01102 | CCKSFT62x122PT3.5-PA66HIRHS-BK |  Details

    Add to watchlist
    Downloads
    Colour Black (BK)
    Material Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
    PART DESCRIPTION CCKSFT62x122PT3.5-PA66HIRHS-BK
    Pack Cont. 1000pcs.
    Package Content packed in bag
    Type CCKSFT62x122PT3.5
    Height (H) 13.8mm
    Length (L) 27.5mm
    Panel Thickness max. 3.3 - 3.7mm
    Width (W) 16.0mm
    for Hole ⌀ (FH) 6.2 x 12.2 mm
    for Panel Thickness min - max 3.3 - 3.7 mm
    Country of Origin DE
    GTIN-13 / EAN 4031026452043
    Packaging 2 - Height (m) 0.22m
    Packaging 2 - Length (m) 0.58m
    Packaging 2 - Qty 10000
    Packaging 2 - Type carton
    Packaging 2 - Volume (m³) 0.0485m³
    Packaging 2 - Weight (kg) 10.70kg
    Packaging 2 - Width (m) 0.38m
    Packaging 3 - Height (m) 0.22m
    Packaging 3 - Length (m) 0.58m
    Packaging 3 - Qty 10000
    Packaging 3 - Type carton
    Packaging 3 - Volume (m³) 0.0485m³
    Packaging 3 - Width (m) 0.38m
    Packaging 4 - Height (m) 0.14m
    Packaging 4 - Length (m) 1.20m
    Packaging 4 - Qty 200000
    Packaging 4 - Type pallet
    Packaging 4 - Volume (m³) 0.134m³
    Packaging 4 - Weight (kg) 200.0kg
    Packaging 4 - Width (m) 0.80m
    ETIM 7.0 Key EC000127
    ETIM 8.0 Key EC000127
    ETIM 9.0 Key EC000127
    UNSPSC Key 39121702
