17/07/2024

Corrugated tube clip for screw fixation/with pipe/tube holder, ∅16.0mm, black, 50pcs.
Art.-No. 151-02981 | CDC16S60.5M6-PA66HIRHS-BK |  Details

Living hinge allows placement and positioning of tubing before locking in place.

    Package size
    Add to watchlist
    Downloads Datasheet
    Colour Black (BK)
    Key product features for convoluted tubes or with rib
    Material Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
    PART DESCRIPTION CDC16S60.5M6-PA66HIRHS-BK
    Pack Cont. 50pcs.
    Package Content packed in carton
    Type CDC16S60.5M6
    Variant Clamps
    Attach to Ø 16
    Bundle Diameter max (metric) 16.0mm
    Bundle ∅ 16.0mm
    Diameter (D) 17.4mm
    Height (H) 61.9mm
    Inner Diameter D (Imperial) 0.95"
    Inside Ø (ID) 24.2mm
    Length (L) 88.3mm
    Nominal ∅ 0.63"
    Nominal ∅ 16.0mm
    Outside ∅ (OD2) 0.69"
    Outside ∅ (OD2) 17.4mm
    Width (W) 23mm
    for Hole ∅ (FH) 6.5 mm
    ∅ (D2) 24.2mm
    ∅ D 0.69"
    ∅ D2 0.95"
    CE Certification No
    CSA Certified No
    Flammability UL 94 HB
    Halogen-free No
    Hazardous Goods No
    Operating Temperature -40 °C to +110 °C
    ROHS compliant Yes
    Specifications
    UL Listed (US and Canada) No
    UL Listed (US and Canada) No
    UL Recognized (US and Canada) No
    UL Recognized (US and Canada) No
    UV-Stabilised No
    Country of Origin MX
    GTIN-13 / EAN 4031026715261
    Packaging 3 - Height (m) 0.352m
    Packaging 3 - Length (m) 0.572m
    Packaging 3 - Type box
    Packaging 3 - Volume (m³) 0.0703m³
    Packaging 3 - Width (m) 0.349m
    ETIM 7.0 Key EC000127
    ETIM 8.0 Key EC000127
    ETIM 9.0 Key EC000127
    UNSPSC Key 39131601
