26/12/2024

Corrugated tube clip, grey, 700pcs.
Art.-No. 151-02665 | CDC22FT6.35CC6-PP-GY |  Details

Self-affixing fir tree configuration.

    Add to watchlist
    Downloads Datasheet
    Colour Grey (GY)
    Fixation Method Fir Tree
    Material Polypropylene (PP)
    PART DESCRIPTION CDC22FT6.35CC6-PP-GY
    Pack Cont. 700pcs.
    Package Content packed in carton
    Type CDC22FT6.35CC6
    Bundle Diameter max (metric) 6.0mm
    Bundle ∅ 6.0mm
    Diameter (D) 23.7mm
    Height (H) 86.0mm
    Length (L) 58.8mm
    Width (W) 10.2mm
    for Hole ∅ (FH) 7.24 mm
    ∅ (D2) 31.2mm
    ∅ D 0.93"
    ∅ D2 1.23"
    CE Certification No
    CSA Certified No
    Flammability UL 94 HB
    Halogen-free No
    Hazardous Goods No
    Operating Temperature -40 °C to +115 °C
    ROHS compliant Yes
    Specifications
    UL Listed (US and Canada) No
    UL Listed (US and Canada) No
    UL Recognized (US and Canada) No
    UL Recognized (US and Canada) No
    UV-Stabilised No
    Country of Origin US
    ETIM 7.0 Key EC000464
    ETIM 8.0 Key EC000464
    ETIM 9.0 Key EC000464
    UNSPSC Key 39121702
