01/03/2025

Corrugated tube clip, grey, 2000pcs.
Art.-No. 151-02694 | CDC9AH10.1-PP-GY

Copied
Colour Grey (GY)
Fixation Method arrowhead
Key product features for convoluted tubes or with rib, lockable
Material Polypropylene (PP)
PART DESCRIPTION CDC9AH10.1-PP-GY
Pack Cont. 2000pcs.
Package Content packed in carton
Type CDC9AH10.1
⌀ (D2) 16.0mm
⌀ D 0.42"
⌀ D2 0.63"
Bundle ⌀ 9.0mm
Bundle Diameter max (metric) 9.0mm
Diameter (D) 10.6mm
Height (H) 32.5mm
Length (L) 25.3mm
Width (W) 7.6mm
for Hole ⌀ (FH) 6.35 mm
CE Certification No
CSA Certified No
Flammability UL 94 HB
Halogen-free No
Hazardous Goods No
Operating Temperature -40 °C to +115 °C
ROHS compliant Yes
Specifications
Source products are manufactured with plastics recovered from recycled waste or marine environments, derived from renewable plant-based sources, or use materials with lower equivalent emissions. HellermannTyton also offers product solutions that – by design – reduce waste or support reusability and recyclability.<BR>ReSource highlights HellermannTyton products that are made from reccled waste or from virgin materials with relatively lower carbon emissions. Source products are manufactured with plastics recovered from recycled waste or marine environments, derived from renewable plant-based sources, or use materials with lower equivalent emissions. HellermannTyton also offers product solutions that – by design – reduce waste or support reusability and recyclability.
ReSource highlights HellermannTyton products that are made from reccled waste or from virgin materials with relatively lower carbon emissions.
UL Listed (US and Canada) No
UL Listed (US and Canada) No
UL Recognized (US and Canada) No
UL Recognized (US) No
UV-Stabilised No
Country of Origin US
ETIM 7.0 Key EC000127
ETIM 8.0 Key EC000127
ETIM 9.0 Key EC000127
UNSPSC Key 31162906
