Connector clip for hole (round), grey, 500pcs.
Art.-No. 151-01853
| FT6LG.YAZ.CONNECT-TS-PA46-GY
|
Details
- Connector easily installed by simply pushing into place
- Connection can be released (non-destructive)
- One fir tree foot part can be used for a variety of panel thicknesses
- Disc covers the hole to prevent dirt and water gaining access
- For twist protection: Variants with additional stick or for oval holes
More products in this product group:
| Application | The connector clips used here have been designed for electronic cables and cable sets used in the automotive industry. |
| Colour | Grey (GY) |
| Fixation Method | Fir Tree |
| Material | Polyamide 4.6 (PA46) |
| PART DESCRIPTION | FT6LG.YAZ.CONNECT-TS-PA46-GY |
| Pack Cont. | 500pcs. |
| Package Content packed in | bag |
| Product Group | Connector Clips for Round Holes |
| Type | FT6LG.YAZ.CONNECT-TS |
Download
|
|
|
| Country of Origin | DE |
| Customs Number | 39269097 |
| GTIN-13 / EAN | 4031026574691 |
| Packaging 1 - Height (m) | 0.035m |
| Packaging 1 - Length (m) | 0.225m |
| Packaging 1 - Qty | 500 |
| Packaging 1 - Type | bag |
| Packaging 1 - Volume (m³) | 0.00213m³ |
| Packaging 1 - Weight (kg) | 0.544362kg |
| Packaging 1 - Width (m) | 0.27m |
| Packaging 3 - Height (m) | 0.368m |
| Packaging 3 - Length (m) | 0.584m |
| Packaging 3 - Qty | 15000 |
| Packaging 3 - Type | box |
| Packaging 3 - Volume (m³) | 0.083m³ |
| Packaging 3 - Weight (kg) | 17.15086kg |
| Packaging 3 - Width (m) | 0.386m |
| Packaging 4 - Height (m) | 1.248m |
| Packaging 4 - Length (m) | 1.2m |
| Packaging 4 - Qty | 180000 |
| Packaging 4 - Type | pallet |
| Packaging 4 - Volume (m³) | 1.198m³ |
| Packaging 4 - Weight (kg) | 226.86kg |
| Packaging 4 - Width (m) | 0.8m |
