Cable clip for stud, Dmin=19.0mm, Dmax=28.0mm
Art.-No. 151-00213
| IAHC3T-PA66HIRHS-BK
|
Details
This product is not available anymore.
Alternative product available
- Push and click closure
- Coupling elements of the IAHC variants allow parts to interconnect
- Clip is clicked into a specific hole
- IAHC( )T can only be connected with another IAHC element
More products in this product group:
| Application | Offering a simple and secure method of attaching cables to panels. Originally designed for the automotive industry, these products are used in a wide range of applications with sheet metal panels across various industries. |
| Colour | Black (BK) |
| Key product features | for faster processing, for multiple routing, vibration absorbing, releasable, removable |
| Material | Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS) |
| PART DESCRIPTION | IAHC3T-PA66HIRHS-BK |
| Pack Cont. | 400pcs. |
| Package Content packed in | carton |
| Product Family | IAHC-Serie |
| Product Group | Fixing Elements for Tubes and Harnesses with Automatic Locking Feature, interconnectable |
| Short Description | Bundling clip 40x10 mm, automatic locking, heat stabilised, high impact modified, black |
| Type | IAHC3T |
Download
|
|
|
| Country of Origin | FR |
| Customs Number | 39269097 |
| GTIN-13 / EAN | 4031026265209 |
| Packaging 1 - Height (m) | 0.14m |
| Packaging 1 - Length (m) | 0.385m |
| Packaging 1 - Qty | 400 |
| Packaging 1 - Type | bag |
| Packaging 1 - Volume (m³) | 0.01563m³ |
| Packaging 1 - Weight (kg) | 2.588001kg |
| Packaging 1 - Width (m) | 0.29m |
| Packaging 3 - Height (m) | 0.15m |
| Packaging 3 - Length (m) | 0.4m |
| Packaging 3 - Qty | 400 |
| Packaging 3 - Type | box |
| Packaging 3 - Volume (m³) | 0.018m³ |
| Packaging 3 - Weight (kg) | 2.957001kg |
| Packaging 3 - Width (m) | 0.3m |
| Packaging 4 - Height (m) | 1.194m |
| Packaging 4 - Length (m) | 1.2m |
| Packaging 4 - Qty | 22400 |
| Packaging 4 - Type | pallet |
| Packaging 4 - Volume (m³) | 1.146m³ |
| Packaging 4 - Weight (kg) | 186.592kg |
| Packaging 4 - Width (m) | 0.8m |
IAHC3T
151-02884
