Cable clip with pipe/tube holder, Dmin=23.0mm, Dmax=29.0mm, nom⌀=26.0 mm, nom⌀2=7.0 mm
Art.-No. 156-02201 | MOC26FMOC7M180-PA66HIRHSUV-BK |

Copied
A rotatable dual routing clip that keeps two routings secured and separated.

    Add to watchlist
    Downloads
    Colour Black (BK)
    Material Polyamide 6.6, high impact modified, heat and UV-stabilised (PA66HIRHSUV)
    PART DESCRIPTION MOC26FMOC7M180-PA66HIRHSUV-BK
    Pack Cont. 2000
    Package Content packed in carton
    Type MOC26FMOC7M180
    Variant Clip to Clip Transverse
    Bundle ⌀ 23.0-29.0mm
    Bundle ⌀ 2 max. 8.0mm
    Bundle ⌀ 2 min. 6.0mm
    Bundle ⌀ max. 29.0mm
    Bundle ⌀ min. 23.0mm
    Bundle Diameter Nom. (ND) 26.0 mm
    Bundle Diameter Nom. 2 (ND2) 7.0 mm
    Depth (D) 12.0mm
    Height (H) 41.0mm
    Height (H2) 11.6mm
    Length (L) 51.99mm
    Length (L2) 28.0mm
    CE Certification No
    CSA Certified No
    Flammability UL 94 HB
    Halogen-free Yes
    Operating Temperature -40 °C to +105 °C
    ROHS compliant Yes
    Specifications
    UL Listed (US and Canada) No
    UL Listed (US and Canada) No
    UL Recognized (US and Canada) No
    UL Recognized (US) No
    UV-Stabilised Yes
    Country of Origin MX
    GTIN-13 / EAN 4031026716237
    Packaging 1 - Type carton
    Packaging 1 - Weight (kg) 204.82kg
    ETIM 7.0 Key EC000127
    ETIM 8.0 Key EC000127
    ETIM 9.0 Key EC000127
    UNSPSC Key 39121702
