P-clamp medium, Dmin=12.7mm, Dmax=19.5mm, ∅M10, 180°, black, 200pcs.
Art.-No. 151-02285
| RCB180MM10EC-PA66HIRHSUV/ST/EP-BK
|
Details
- Ratchet P-Clamp B-Series for bundle diameters from 13.2 mm to 19.5 mm
- One-piece ratchet closure design allows for easy installation during pre- or final assembly
- Multiple configurations handle a wide range of diameters and applications, reducing part inventory
- Clamp interior is designed to guide and center bundle to reduce pinching
- Easy release feature allows for quick adjustments and maintenance
- Impact modified, heat and UV stabilized PA66 provides long-term durability, in- and outdoors
- Steel mounting plate tolerates high torque mounting and is treated to resist chemicals and salt spray
More products in this product group:
Application | The Ratchet P-Clamp family offers versatility when managing wires, cables and hoses. The robust design and durable materials make it ideal for heavy duty applications, both in- and outdoors. The one-piece adjustable clamp can be closed by hand to the desired diameter. The release feature provides easy and nondestructive removal of cables simply by using a flat-head screwdriver. This nondestructive release allows the clamp to be reused without removing or replacing any bolts or screws. The Ratchet P-Clamp is offered in four sizes and multiple mounting configurations. |
Colour | Black (BK) |
Fixation Method | Screw Mounting |
Key product features | vibration absorbing, removable, releasable, for multiple routing |
Material | Polyamide 6.6, high impact modified, heat and UV-stabilised (PA66HIRHSUV), Steel (ST), Epoxy resins (EP) |
PART DESCRIPTION | RCB180MM10EC-PA66HIRHSUV/ST/EP-BK |
Pack Cont. | 200pcs. |
Package Content packed in | box |
Product Family | For bundle diameters from 12.7 mm to 19.5 mm, B-Series |
Product Group | Ratchet P-Clamp |
Type | RCB180MM10EC |
Variant | Medium |
CE Certification | No |
CSA Certified | No |
Flammability | UL 94 HB |
Halogen-free | Yes |
Operating Temperature | -40 °C to +105 °C |
ROHS compliant | Yes |
Reusable (Yes/No) | Yes |
Specifications | |
UL Listed (US and Canada) | No |
UL Listed (US and Canada) | No |
UL Recognized (US and Canada) | No |
UL Recognized (US and Canada) | No |
UV-Stabilised | Yes |
