Bundling clip for hole (oval), L=50.0mm, SO=20.0mm, black, 500pcs.
Art.-No. 151-01255
| SOC20SFT712-MD-PA66HIRHS/EPDM-BK
|
Details
- Simple installation, tool-free
- Defined distance to the mounting
More products in this product group:
| Application | These cable clips are particularly popular in the automotive industry, as cable harnesses can be easily installed in different areas of the vehicle. Due to their flat and lightweight design, they are an optimal solution for limited spaces.hole |
| Colour | Black (BK) |
| Material | Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS), Ethylene Propylene Diene Terpolymer rubber free of Nitrosamine (EPDM) |
| PART DESCRIPTION | SOC20SFT712-MD-PA66HIRHS/EPDM-BK |
| Pack Cont. | 500pcs. |
| Package Content packed in | bag |
| Product Family | Oval holes, sealed |
| Product Group | Bundling Clips with Arrowhead for Distance Routing |
| Short Description | Bundling Clip, oval hole 7.0 x 12.0 mm, arrow head, sealed, PA66HIRHS / EPDM, black |
| Type | SOC20SFT712-MD |
Download
|
|
|
| Country of Origin | CN |
| Customs Number | 39269097 |
| GTIN-13 / EAN | 4031026479767 |
| Packaging 1 - Height (m) | 0.13m |
| Packaging 1 - Length (m) | 0.31m |
| Packaging 1 - Qty | 500 |
| Packaging 1 - Type | bag |
| Packaging 1 - Volume (m³) | 0.01249m³ |
| Packaging 1 - Weight (kg) | 1.150001kg |
| Packaging 1 - Width (m) | 0.31m |
| Packaging 3 - Height (m) | 0.2m |
| Packaging 3 - Length (m) | 0.59m |
| Packaging 3 - Qty | 3000 |
| Packaging 3 - Type | box |
| Packaging 3 - Volume (m³) | 0.046m³ |
| Packaging 3 - Weight (kg) | 7.720006kg |
| Packaging 3 - Width (m) | 0.39m |
| Packaging 4 - Height (m) | 1.144m |
| Packaging 4 - Length (m) | 1.2m |
| Packaging 4 - Qty | 60000 |
| Packaging 4 - Type | pallet |
| Packaging 4 - Volume (m³) | 1.098m³ |
| Packaging 4 - Weight (kg) | 175.4kg |
| Packaging 4 - Width (m) | 0.8m |
SOC32SFT65X130-MD
151-01331
