Cable clip, Dmin=12.7mm, Dmax=19.1mm
Art.-No. 151-00667 | WAC075-PVC-GY |  Details

    Add to watchlist
    Downloads Datasheet
    Colour Grey (GY)
    Material Polyvinylchloride (PVC)
    PART DESCRIPTION WAC075-PVC-GY
    Pack Cont. 500pcs.
    Package Content packed in bag
    Type WAC075
    Bundle Diameter max (metric) 19.1mm
    Bundle ∅ 12.7-19.1mm
    Bundle ∅ min. 12.7mm
    Height (H) 15.8mm
    Height (H2) 26.7mm
    Length (L) 28.7mm
    Thickness of Adhesive (TA) nom. 0.036"
    Thickness of Adhesive (TA) nom. 0.91mm
    Width (W) 25.4mm
    Adhesive Self adhesive
    CE Certification No
    CSA Certified No
    Flammability UL 94 V0 (excluding adhesive)
    Operating Temperature +50 °C
    ROHS compliant No
    UL Listed (US and Canada) No
    UL Listed (US and Canada) No
    UL Recognized (US and Canada) No
    UL Recognized (US and Canada) No
    UV-Stabilised No
    Country of Origin US
    GTIN-13 / EAN 4031026725642
    Packaging 3 - Height (m) 0.2159m
    Packaging 3 - Length (m) 0.606425m
    Packaging 3 - Type box
    Packaging 3 - Volume (m³) 0.052m³
    Packaging 3 - Width (m) 0.396875m
    ETIM 7.0 Key EC000127
    ETIM 8.0 Key EC000127
    ETIM 9.0 Key EC000127
    UNSPSC Key 39121702
