BSPW10-PET-OG
Art.-No. 170-03236 | BSPW10-PET-OG |  Details

    Add to watchlist
    Downloads Datasheet
    Colour Orange (OG)
    Material Polyester (PET)
    Open, post termination (Yes/No) No
    PART DESCRIPTION BSPW10-PET-OG
    Pack Cont. 30.48m
    Package Content packed in reel
    Size 1"
    Type BSPW10
    Bundle Diameter max (metric) 25.4mm
    Bundle ∅ 2.5-25.4mm
    Bundle ∅ min. 2.5mm
    Diameter (D) 25.0mm
    Length (L) 30.5m
    Nominal ∅ 0.984"
    Nominal ∅ 25.0mm
    Wall (WT) 0.7mm
    Wall (WT) 0.027"
    ∅ D 1.0"
    CE Certification No
    CSA Certified No
    Flammability FMVSS 302, UL 94 V0
    Halogen-free No
    Melting Point +250 °C
    Operating Temperature -70 °C to +150 °C
    ROHS compliant Yes
    Specifications
    UV-Stabilised No
    Country of Origin MX
    GTIN-13 / EAN 4031026683027
    Reel Length 100.0ft
    Reel Length 30.5m
    ETIM 7.0 Key EC001182
    ETIM 8.0 Key EC001182
    ETIM 9.0 Key EC001182
    UNSPSC Key 39131602
    Cable protection conduits Cable protection conduits

    Cable Protection Conduits

    No cable can meet the demands posed today in terms of abrasion resistance, tensile strength and form consistency or impact resistance without having appropriate cable protection. Cable protection tubes...
