19/12/2024

Low Profile Right Angle Boots
Art.-No. 422-30306 | 333F364-9-PO-X-BK |  Details

333F322-385 Series supplied / fully recovered.

    • Lightweight strain relief for small cable diameters requiring high shrink ratio
    • Right angle connector housing with long cable entry and inner lip
    Package size
    Add to watchlist
    Downloads
    Application Heat Shrinkable Moulded Shapes for use in Electical and Electronic Cable Harness Applications
    Colour Black (BK)
    Material Polyolefin, cross-linked (PO-X)
    PART DESCRIPTION 333F364-9-PO-X-BK
    Pack Cont. 5pcs.
    Package Content packed in bag
    Product Family Helashrink 333F Series, with adapter lip, 90° angle
    Product Group Low Profile Right Angle Boots
    Shrink Ratio 3:1
    Type 333F364-9
    Variant For plug
    Angle 90
    Flexibility Flexible
    HW ± 1.5 1.7mm
    JW ± 0.8 1.5mm
    P ± 10 % 185.1mm
    R ± 15 % 24.1mm
    S ± 1.5 1.7mm
    T ± 0.8 1.8mm
    Weight/Unit .015kg
    ∅H max. b 27.9mm
    ∅H min. a 38.8mm
    ∅J max. b 10.9mm
    ∅J min. a 31.4mm
    Flammability ASTM D635
    Min. Shrink Temperature - °C +100 °C
    Operating Temperature -55 °C to +120 °C
    ROHS compliant Yes
    Specifications
    Country of Origin GB
    GTIN-13 / EAN 5022660457326
    ETIM 7.0 Key EC002464
    ETIM 8.0 Key EC002464
    ETIM 9.0 Key EC002464
    UNSPSC Key 39121721
