FPU40BU-10M-GS/PUR-BU
Art.-No. 166-90681 | FPU40BU-10M-GS/PUR-BU |  Details

Halogen Free.

    Add to watchlist
    Downloads
    Colour Blue (BU)
    Material Galvanised Steel (GS), Polyurethane resin (PUR)
    PART DESCRIPTION FPU40BU-10M-GS/PUR-BU
    Pack Cont. 10.0m
    Package Content packed in reel
    Type FPU40BU-10M
    Bending Radius min. (BR) 3.15"
    Bending Radius min. (R) 80mm
    Diameter (D) 37.6mm
    Nominal ∅ 1.25"
    Nominal ∅ 40.0mm
    Outside Ø (OD) 44.5mm
    Outside ∅ (OD) 1.75"
    Weight 885g/m
    ∅ D 1.48"
    CSA Certified No
    Flammability UL 94 V0
    Halogen-free Yes
    Operating Temperature -40 °C to +100 °C
    ROHS compliant Yes
    Specifications
    UL Listed (US and Canada) No
    UL Listed (US and Canada) No
    UL Recognized (US and Canada) No
    UL Recognized (US and Canada) No
    UV-Stabilised No
    Country of Origin GB
    GTIN-13 / EAN 4031026561646
    Packaging 1 - Weight (kg) 8.85kg
    Reel Length 32.8ft
    Reel Length 10.0m
    UNSPSC Key 39131706
    Metal conduits Metal conduits

    Metal conduits

    Metal conduits from HellermannTyton: Standard metal conduits, coated metal conduits, liquid tight metal conduits and matching metal conduit fittings. Discover now!
