LFHU63B-10M-GS/PO-BK
Art.-No. 166-90665 | LFHU63B-10M-GS/PO-BK |  Details

    Add to watchlist
    Downloads
    Colour Black (BK)
    Material Galvanised Steel (GS), Polyolefin (PO)
    PART DESCRIPTION LFHU63B-10M-GS/PO-BK
    Pack Cont. 10.0m
    Package Content packed in reel
    Type LFHU63B-10M
    Bending Radius min. (BR) 4.53"
    Bending Radius min. (R) 115mm
    Diameter (D) 57.0mm
    Length (L) 10.0m
    Nominal ∅ 2.5"
    Nominal ∅ 63mm
    Outside Ø (OD) 64.5mm
    Outside ∅ (OD) 2.54"
    Weight 1470g/m
    ∅ D 2.24"
    CSA Certified No
    Flammability EN IEC 61386-1
    Halogen-free Yes
    Operating Temperature -25 °C to +90 °C
    ROHS compliant Yes
    Self extinguishing Yes
    Specifications
    UL Listed (US and Canada) No
    UL Listed (US and Canada) No
    UL Recognized (US and Canada) No
    UL Recognized (US and Canada) No
    UV-Stabilised No
    Country of Origin GB
    GTIN-13 / EAN 4031026561486
    Packaging 1 - Weight (kg) 14.7kg
    Reel Length 32.8ft
    Reel Length 10.0m
    UNSPSC Key 39131706
