LTP63-M63-C-NPB-ML
Art.-No. 166-90778 | LTP63-M63-C-NPB-ML |  Details

    Add to watchlist
    Downloads
    Colour Metal (ML)
    Material Nickel Plated Brass (NPB)
    PART DESCRIPTION LTP63-M63-C-NPB-ML
    Pack Cont. 1pc.
    Package Content packed in pcs.
    Thread type metric
    Type LTP63-M63-C
    Variant Straight
    Nominal ∅ 2.5"
    Nominal ∅ 63mm
    Thread Size M63
    clearance hole Diameter (Imperial) 1.93"
    clearance hole Diameter (Metric) 1mm
    CSA Certified No
    Halogen-free Yes
    IP-Rating IP68
    ROHS compliant Yes
    Specifications
    UL Listed (US and Canada) Yes
    UL Listed (US and Canada) Yes
    UL Recognized (US and Canada) No
    UL Recognized (US and Canada) No
    UL-File Number E247502
    UV-Stabilised No
    Country of Origin GB
    GTIN-13 / EAN 4031026581811
    Metal conduits Metal conduits

    Metal conduits

    Metal conduits from HellermannTyton: Standard metal conduits, coated metal conduits, liquid tight metal conduits and matching metal conduit fittings. Discover now!
