Bundle connectors.
Art.-No. 874-00055
| SRV-M_MAXI_fuer_SRV-G_tc_Gr._2-BK
|
Details
- gas- and water-tight up to 0.5 bar
- reusable and applicable for direct burying
- to connect the speedpipe bundles ground SRV-G inside stiffeners SHi needed on both sides
More products in this product group:
Application | The SRV-M and SRV-M MAXI serve for the pressure-tight protection of the connecting points of two buried speedpipe bundles against the penetration of gas and water through the duct gaps. In case of a in-duct solution with jacket pipes up to Ø 63 mm or at the transition to a buried bundle, the connectors connect the complete duct system gas-, pressure- and water-tight as well. The split SRV-M MAXI for SRV-G tc are suitable for the pressure-tight connection of speedpipe bundles ground SRV-G tc. |
Application Method | Application for SRV-G 12×12 tc, SRV-G 12×12 + 1×16 tc, SRV-G 10×14 tc, SRV-G 4×20 tc, SRV-G 5×20 tc |
Colour | Black (BK) |
PART DESCRIPTION | SRV-M_MAXI_fuer_SRV-G_tc_Gr._2-BK |
Pack Cont. | 2 |
Package Content packed in | carton |
Product Family | SRV-M MAXI for SRV-G tc size 2 |
Product Group | Bundle connectors. |
Type | SRV-M_MAXI_fuer_SRV-G_tc_Gr._2 |
