HG-DC1500-PA6-BK
Art.-No. 166-11813 | HG-DC1500-PA6-BK |  Details

    Add to watchlist
    Downloads
    Colour Black (BK)
    Material Polyamide 6 (PA6)
    PART DESCRIPTION HG-DC1500-PA6-BK
    Pack Cont. 25m
    Package Content packed in reel
    Pitch Type coarse
    Type HG-DC1500
    Bending Radius min. (BR) 9.45"
    Bending Radius min. (R) 240mm
    Inner Diameter D (Imperial) 1.70"
    Inside Ø (ID) 43mm
    Length (L) 25m
    NW ∅ 48mm
    Nominal ∅ 2.13"
    Nominal ∅ 54mm
    Outside Ø (OD) 54.5mm
    Outside ∅ (OD) 2.15"
    CE Certification No
    CSA Certified No
    Flammability EN IEC 61386
    Halogen-free Yes
    Operating Temperature -40 °C to +120 °C
    ROHS compliant Yes
    Self extinguishing Yes
    Specifications
    UL Listed (US and Canada) No
    UL Listed (US and Canada) No
    UL Recognized (US and Canada) No
    UL Recognized (US and Canada) No
    UV-Stabilised No
    Country of Origin DE
    GTIN-13 / EAN 4031026490472
    UNSPSC Key 39131601
