HG-SWSL0500-PA6-BK
Art.-No. 166-90271 | HG-SWSL0500-PA6-BK |  Details

    Add to watchlist
    Downloads
    Colour Black (BK)
    Material Polyamide 6 (PA6)
    PART DESCRIPTION HG-SWSL0500-PA6-BK
    Pack Cont. 30.48m
    Package Content packed in reel
    Pitch Type fine
    Type HG-SWSL0500
    Bending Radius min. (BR) 1.78"
    Bending Radius min. (R) 45mm
    Inner Diameter D (Imperial) 0.66"
    Inside Ø (ID) 16.7mm
    Length (L) 30.5m
    NW ∅ 17mm
    Nominal ∅ 0.5"
    Nominal ∅ 21mm
    Outside Ø (OD) 21.2mm
    Outside ∅ (OD) 0.84"
    CE Certification No
    CSA Certified No
    Flammability UL 94 V2
    Halogen-free Yes
    Operating Temperature -40 °C to +120 °C
    Operating Temperature Moving -20 °C to +100 °C
    ROHS compliant Yes
    Specifications
    UL Listed (US and Canada) No
    UL Listed (US and Canada) No
    UL Recognized (US and Canada) No
    UL Recognized (US and Canada) No
    UV-Stabilised No
    Country of Origin GB
    GTIN-13 / EAN 4031026485508
    UNSPSC Key 39131601
