Accessory, Helawrap, blue, 10pcs. (HAT8)
Art.-No. 161-60001 | HAT8-PA66-BU |  Details

Applicator tools are available for every Helawrap cover size.

    • Bundle cable rapidly and effortlessly
    • Glides smoothly and securely through cover
    • Easy insertion of cable
    Package size
    Add to watchlist
    Downloads Datasheet
    Application The HAT application tools are used with Helawrap HWPP, HWPAV0 and HWPPMC cable covers to bundle and protect cables rapidly and efficiently. There is a specially designed HAT application tool for each size Helawarp cable cover.
    Application Method Place cables in applicator, then zip through cover sleeve.
    Colour Blue (BU)
    Material Polyamide 6.6 (PA66)
    PART DESCRIPTION HAT8-PA66-BU
    Pack Cont. 10pcs.
    Package Content packed in bag
    Product Family HAT
    Product Group Applicator Tool
    Short Description Applicator tool for professional 8mm cable cover
    Type HAT8
    Nominal ∅ 0.31"
    Nominal ∅ 8mm
    Weight/Unit 0.003691kg
    CE Certification No
    CSA Certified No
    ELV compliant (Article 4 - 2) YES
    Halogen-free Yes
    Hazardous Goods No
    ROHS compliant Yes
    Specifications
    UL Listed (US and Canada) No
    UL Listed (US and Canada) No
    UL Recognized (US and Canada) No
    UL Recognized (US and Canada) No
    UV-Stabilised No
    Country of Origin GB
    Customs Number 39269097
    GTIN-13 / EAN 5022660178313
    Packaging 1 - Height (m) 0.015m
    Packaging 1 - Length (m) 0.21m
    Packaging 1 - Qty 10
    Packaging 1 - Type bag
    Packaging 1 - Volume (m³) 0.00039m³
    Packaging 1 - Weight (kg) 0.036915kg
    Packaging 1 - Width (m) 0.125m
    ETIM 7.0 Key EC001177
    ETIM 8.0 Key EC001177
    ETIM 9.0 Key EC001177
    UNSPSC Key 39131604
