PSR038-45-0500-PA66-BK
Art.-No. 166-90124 | PSR038-45-0500-PA66-BK |  Details

External NPT thread provides a secure connection.

    Add to watchlist
    Downloads
    Colour Black (BK)
    Material Polyamide 6.6 (PA66)
    PART DESCRIPTION PSR038-45-0500-PA66-BK
    Pack Cont. 10pcs.
    Package Content packed in bag
    Thread type NPT
    Type PSR038-45-0500
    Variant 45°-elbow
    Bore Diameter (Imperial) 0.41"
    Bore Diameter (metric) 10.5
    Length (L) 58mm
    Nominal ∅ 0.38"
    Nominal ∅ 16mm
    Outside Ø (OD) 28mm
    Outside ∅ (OD) 1.10"
    Thread Length (TL) 13mm
    Thread Length (TL) (Imperial) 0.51"
    Thread Size (Imperial) 1/2 "
    clearance hole Diameter (Imperial) 0.827"
    clearance hole Diameter (Metric) 21mm
    CE Certification No
    CSA Certified No
    Flammability UL 94 V2
    Halogen-free Yes
    IP-Rating IP65
    Operating Temperature -40 °C to +120 °C
    ROHS compliant Yes
    Specifications
    UL Listed (US and Canada) No
    UL Listed (US and Canada) No
    UL Recognized (US and Canada) Yes
    UL Recognized (US and Canada) Yes
    UL-File Number E229161
    UV-Stabilised No
    Country of Origin GB
    GTIN-13 / EAN 4031026463186
    UNSPSC Key 39131708
