Cable tie inside serrated, 385x4.65mm, ∅1.6-110mm, black, 100pcs.
Nr. articol 108-00028 | X80L-PA66HIRHS-BK Detalii

  • Inside serrated cable tie
  • High tensile strength around cable bundles
  • Smooth, rounded head design
  • Space saving solution
  • Improved ergonomic design
  • Provides a secure fastening with no lateral movement
arată mai mult

Solicitați acum oferta dumneavoastră individuală

Application The X-Series range of cable ties provides a new and improved design compared with standard cable ties, delivering a range of benefits and enhanced performance. With a new streamlined design and smaller head, the X-Series cable ties provide a superior fixing solution for tight applications, whilst also benefiting from a better grip around the bundle. This professional cable tie range is available in weather resistant and high impact / heat stabilised materials, ensuring these fixings consistently perform well both at high temperatures and in cold environments.
Colour Black (BK)
Identification Plate Position none
Material Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
PART DESCRIPTION X80L-PA66HIRHS-BK
Pack Cont. 100pcs.
Package Content packed in bag
Product Family X-Series
Product Group Cable ties with smart design
Releasable Closure (Yes/No) No
Short Description Cable Tie 385x4.65 with rounded head design PA66HIRHS black
Tie Closure plastic pawl
Type X80L
Variant Inside Serrated
Bundle Diameter max (metric) 110mm
Bundle ∅ 1.6-110mm
Bundle ∅ min. 1.6mm
Length (L) 385mm
Min.Tensile Strength 355N
Thickness (T) 1.35mm
Weight/Unit 0.00259kg
Width (W) 4.65mm
ELV compliant (Article 4 - 2) YES
Flammability UL 94 HB
Halogen-free Yes
Hazardous Goods No
Operating Temperature -40 °C to +105 °C
ROHS compliant Yes
Specifications
Specifications IEC 62275, UL 62275
Country of Origin GB
Customs Number 39269097
GTIN-13 / EAN 5022660342028
Packaging 1 - Height (m) 0.03m
Packaging 1 - Length (m) 0.535m
Packaging 1 - Qty 100
Packaging 1 - Type bag
Packaging 1 - Volume (m³) 0.00241
Packaging 1 - Weight (kg) 0.259001kg
Packaging 1 - Width (m) 0.15m
Packaging 3 - Height (m) 0.192m
Packaging 3 - Length (m) 0.586m
Packaging 3 - Qty 4000
Packaging 3 - Type box
Packaging 3 - Volume (m³) 0.0439
Packaging 3 - Weight (kg) 11.16204kg
Packaging 3 - Width (m) 0.39m
Packaging 4 - Height (m) 1.164m
Packaging 4 - Length (m) 1.2m
Packaging 4 - Qty 80000
Packaging 4 - Type pallet
Packaging 4 - Volume (m³) 1.117
Packaging 4 - Weight (kg) 244.24kg
Packaging 4 - Width (m) 0.8m
ETIM 7.0 Key EC000046
ETIM 8.0 Key EC000046
ETIM 9.0 Key EC000046
UNSPSC Key 39121703
