Fixing tie for edge, inside serrated, ∅1.5-47mm, black, 100pcs.
Nr. articol 156-03135
| T50REC1-3TRIOSET-PA66W-BK
|
Detalii
- Fixing ties multi-way for edges
- A single EdgeClip for a multitude of configurations (single, double, or triple routing, in parallel or perpendicular...)
- Sold with 1 tie, 2 additional ties can be added to fix cables up to 47 mm in diameter
- Tie can be rotated 90° without removing it from the loop
- Cables can be routed above or along the support
- Easy manual installation
- Suitable for panel thicknesses from 1 to 3 mm
- Double-grip metal insert, made of treated steel, for secure retention and significant pull-out resistance
- Solution without drilling or adhesive
- Very good UV resistance
- Cable tie retaining system to prevent slipping through the loops
Solicitați acum oferta dumneavoastră individuală
Solicitați oferta
Mai multe produse în acest grup de produse:
| Application | Fixing tie for edges are ideal when drilling is not an option, and there is no other solution to route cables along an edge. This is often the case when the cables from photovoltaic panels are too short to be attached to substructures. They also prove useful when there is a need to keep solar cables out of metal conduits in the substructure or away from roof surfaces that can be flooded, causing inverter defects over time. The EdgeClip can be easily installed by pushing it onto the metal edge, without any tools. The metal insert ensures significant and reliable resistance to pull-out forces. Fixing tie are made in UV-stabilized PA6.6, specifically developed for photovoltaic applications. |
| Cable Tie | Polyamide 6.6, UV-resistant (PA66W) |
| Colour | Black (BK) |
| Description | Fixing ties multi-way for edges can be used to route cables in any direction thanks to 3 ways with tie rotation option, it offers great flexibility to the installer. This well-designed head allows a multitude of combinations for routing cables above or along an edge, and also allows ties to be swivelled quickly to allow cables to be routed perpendicular or parallel to the support. One or two additional ties can be added for double or triple routing. This fixing solution is quick and easy to install manually and without tools, simply by pushing it onto the edge. It's ideal for applications where no holes need to be drilled, or where the temperature of use means that adhesive solutions are not suitable. Fixing ties multi-way is hygly durable, ideal for outdoor applications. It is for example much used in the photovoltaic industry, where it saves a considerable time during installation. |
| Fixation Method | Edge Clip |
| Identification Plate Position | none |
| Material | Polyamide 6.6, UV-resistant (PA66W) |
| PART DESCRIPTION | T50REC1-3TRIOSET-PA66W-BK |
| Pack Cont. | 100pcs. |
| Package Content packed in | bag |
| Product Family | EdgeClip series,multiple routing, multi-ways |
| Product Group | Fixing tie for edges 3 heads, 1-3 mm |
| Releasable Closure (Yes/No) | No |
| Short Description | Fixing ties multi-way for edges and multi-routing, 200 x 4.7 mm in PA66W Black - T50REC1-3TRIOSET |
| Tie Closure | plastic pawl |
| Type | T50REC1-3TRIOSET |
Descărcare
|
|
|
| Country of Origin | FR |
| Customs Number | 39269097 |
| GTIN-13 / EAN | 4031026698502 |
| Packaging 1 - Height (m) | 0.05m |
| Packaging 1 - Length (m) | 0.3m |
| Packaging 1 - Qty | 100 |
| Packaging 1 - Type | bag |
| Packaging 1 - Volume (m³) | 0.0033m³ |
| Packaging 1 - Weight (kg) | 0.319001kg |
| Packaging 1 - Width (m) | 0.22m |
| Packaging 2 - Type | carton |
| Packaging 3 - Height (m) | 0.3m |
| Packaging 3 - Length (m) | 0.4m |
| Packaging 3 - Qty | 2000 |
| Packaging 3 - Type | box |
| Packaging 3 - Volume (m³) | 0.036m³ |
| Packaging 3 - Weight (kg) | 6.87502kg |
| Packaging 3 - Width (m) | 0.3m |
| Packaging 4 - Height (m) | 1.044m |
| Packaging 4 - Length (m) | 1.2m |
| Packaging 4 - Qty | 48000 |
| Packaging 4 - Type | pallet |
| Packaging 4 - Volume (m³) | 1.002m³ |
| Packaging 4 - Weight (kg) | 186.0kg |
| Packaging 4 - Width (m) | 0.8m |
