Fixing tie for edge, outside serrated, ∅1.0-45.0mm, black, 500pcs.
Nr. articol 156-02700
| T50ROSEC6-8-PA66HS/PA66HIRHS-BK
|
Detalii
- Pre-assembled 2-piece fixing tie with EdgeClip
- Cable tie head can be moved after bundling
- For minimum bundle diameters of 1 mm
- For edges of 6 - 8 mm
Solicitați acum oferta dumneavoastră individuală
Solicitați oferta
Mai multe produse în acest grup de produse:
| Application | These cable ties and EdgeClip assemblies are ideal for use where holes are not acceptable or where due to temperature problems adhesives will fail. These assemblies are widely used for fixing and bundling cables, pipes and hoses within the automotive industry, harness making, panel building and electrical industry. |
| Cable Tie | Polyamide 6.6, heat stabilised (PA66HS) |
| Colour | Black (BK) |
| Fixation Method | Edge Clip |
| Foot Part | Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS) |
| Identification Plate Position | none |
| Material | Polyamide 6.6, heat stabilised (PA66HS), Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS) |
| PART DESCRIPTION | T50ROSEC6-8-PA66HS/PA66HIRHS-BK |
| Pack Cont. | 500pcs. |
| Package Content packed in | bag |
| Product Family | EdgeClip-Series, 6.0 - 8.0 mm, top fixing |
| Product Group | 2-piece fixing ties for edges |
| Short Description | Edge Clip (6-8 mm), cable tie, 2 pieces, top fixing, PA66HS+PA66HIRHS, black |
| Type | T50ROSEC6-8 |
| Variant | Outside Serrated |
| Bundle Diameter max (metric) | 45.0mm |
| Bundle ∅ | 1.0-45.0mm |
| Bundle ∅ min. | 1.0mm |
| Height (H) | 1.3mm |
| Height (H2) | 19.4mm |
| Length (L) | 200.0mm |
| Length (L2) | 13.5mm |
| Min.Tensile Strength | 225N |
| Panel Thickness max. | 6.0 - 8.0mm |
| Weight/Unit | 0.003798kg |
| Width (W) | 4.6mm |
| Width (W2) | 17.8mm |
| for Panel Thickness min - max | 6 - 8 mm |
| for Panel Thickness min - max | 0.2 - 0.3 " |
Descărcare
|
|
|
| Country of Origin | PL |
| Customs Number | 39269097 |
| GTIN-13 / EAN | 4031026623078 |
| Packaging 1 - Height (m) | 0.15m |
| Packaging 1 - Length (m) | 0.47m |
| Packaging 1 - Qty | 500 |
| Packaging 1 - Type | bag |
| Packaging 1 - Volume (m³) | 0.03842m³ |
| Packaging 1 - Weight (kg) | 1.942597kg |
| Packaging 1 - Width (m) | 0.545m |
| Packaging 3 - Height (m) | 0.368m |
| Packaging 3 - Length (m) | 0.584m |
| Packaging 3 - Qty | 3500 |
| Packaging 3 - Type | box |
| Packaging 3 - Volume (m³) | 0.083m³ |
| Packaging 3 - Weight (kg) | 14.418179kg |
| Packaging 3 - Width (m) | 0.386m |
| Packaging 4 - Height (m) | 1.248m |
| Packaging 4 - Length (m) | 1.2m |
| Packaging 4 - Qty | 42000 |
| Packaging 4 - Type | pallet |
| Packaging 4 - Volume (m³) | 1.198m³ |
| Packaging 4 - Weight (kg) | 194.052kg |
| Packaging 4 - Width (m) | 0.8m |
