Blind plug, ∅6.2 x 12.2 mm/6.5 x 12.5 mm, T=0.6 - 6.0mm, black, 7000pcs.
Nr. articol 151-01245 | PLUGFTOVAL-PA66HIRHS-BK Detalii

  • Easy assembly without the need of a tool
  • Disc of the part covers the hole and minimises ingress of dust, dirt and water
  • Standard geometry for example fir tree or arrowhead

Solicitați acum oferta dumneavoastră individuală

Application Products were developed especially for the automotive industry. Application in trunks, doors, wheel housing and dash panels. Parts are even used for optical reasons.
Colour Black (BK)
Fixation Method Fir Tree for oval holes
Material Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
PART DESCRIPTION PLUGFTOVAL-PA66HIRHS-BK
Pack Cont. 7000pcs.
Package Content packed in carton
Product Group Blind Plugs
Type PLUGFTOVAL
Fixing Hole Shape Oval
Height (H) 15.6mm
Height (H2) 12.85mm
Length (L) 23.6mm
Panel Thickness max. 0.6 - 6.0mm
Weight/Unit 0.000762kg
Width (W) 17.63mm
for Hole ∅ (FH) 6.2 x 12.2 mm, 6.5 x 12.5 mm, 6.5 x 13.0 mm, 7.0 x 12.0 mm
for Panel Thickness min - max 0.6 - 6 mm
CE Certification No
CSA Certified No
ELV compliant (Article 4 - 2) YES
Flammability UL 94 HB
Hazardous Goods No
Operating Temperature -40 °C to +110 °C
ROHS compliant Yes
Specifications
UL Listed (US and Canada) No
UL Listed (US and Canada) No
UL Recognized (US and Canada) No
UL Recognized (US) No
UV-Stabilised No
Country of Origin US
Customs Number 39269097
GTIN-13 / EAN 4031026477923
Packaging 1 - Height (m) 0.18m
Packaging 1 - Length (m) 0.506m
Packaging 1 - Qty 7000
Packaging 1 - Type bag
Packaging 1 - Volume (m³) 0.02814
Packaging 1 - Weight (kg) 5.334001kg
Packaging 1 - Width (m) 0.309m
Packaging 3 - Height (m) 0.212725m
Packaging 3 - Length (m) 0.51435m
Packaging 3 - Qty 7000
Packaging 3 - Type box
Packaging 3 - Volume (m³) 0.0347
Packaging 3 - Weight (kg) 5.954001kg
Packaging 3 - Width (m) 0.3175m
Packaging 4 - Height (m) 1.209m
Packaging 4 - Length (m) 1.2m
Packaging 4 - Qty 140000
Packaging 4 - Type pallet
Packaging 4 - Volume (m³) 1.161
Packaging 4 - Weight (kg) 140.08kg
Packaging 4 - Width (m) 0.8m
ETIM 7.0 Key EC000464
ETIM 8.0 Key EC000464
ETIM 9.0 Key EC000464
UNSPSC Key 39121717
