Label, white, thermal transfer print, 6.35x25.40mm, 7500pcs.
Nr. articol 596-01029 | TAG01TD3-829-WH | Detalii

Ideal for machinery operating in high temperature areas (up to +150 °C)
For applications on flat surfaces
Chemical resistant polyester foil
For permanent and ageing-resistant identification
Barcodes and alphanumeric text remain pin sharp on this high quality material
White colour guarantees a suitable contrast for all barcode scanners to read printed barcodes

Solicitați acum oferta dumneavoastră individuală

Solicitați oferta

Găsiți un distribuitor în apropierea dumneavoastră

Mai multe produse în acest grup de produse:

Application	This white label is scratch-resistant and is ideal for usage as identification or name plate in industrial environments. The high temperature range suits a wide range of applications on flat surfaces. The adhesive is also suitable for critical surfaces like plastic and paint. Designing and printing labels is simple and users can quickly print out professional labels in a matter of moments when using TagPrint Pro labelling software.
Application Method	The functionality and durability of the labels can be negatively affected if improperly processed or applied. All surfaces to be bonded must be clean, dry as well as free from dust and grease. Avoid touching the adhesive surface of the label as this could impair the application performance.
Chem. Material Properties	Excellent resistance to alcohol, fuel, cleaning solvents, butanol, ethyl- and and butylcellsolve solvent, battery acid.
Colour	White gloss (GSWH)
Material	Type 829, Polyester, white (829)
Mech. material properties	Adhesive suitable for critical surfaces.
PART DESCRIPTION	TAG01TD3-829-WH
Pack Cont.	7500pcs.
Package Content packed in	reel
Product Family	Helatag 829
Product Group	Asset identification label, thermal transfer
Self adhesive (Yes/No)	Yes
Short Description	Label TAG01TD3 type 829 25.40x6.35 mm white
Type	TAG01TD3


HR	28.57mm
Height (H)	6.35mm
Print Method	thermal transfer print
Thickness of Foil	50
Thickness of foil test method	ASTM D3652
VR	8.89mm
Weight/Unit	0.000047kg
Width (W)	25.40mm
Width of Liner (WL)	89.00mm

Adhesive	Acrylic
Curing Temperature	from +10 °C
ELV compliant (Article 4 - 2)	YES
Halogen-free	Yes
Hazardous Goods	No
Initial tack	540g/cm²
Initial tack	ASTM D2979
Operating Temperature	-40 °C to +150 °C
ROHS compliant	Yes
Recommended Ribbon Type	TT822OUT
Shear strength	50h
Shear strength test method	FINAT FTM 8
Shelf Life	Minimum 1 year upon receipt / maximal 2 years after production date.
Specifications
Specifications	BS-2848 Type 3 Class BST
UL Listed (US and Canada)	Yes

Country of Origin	DE
Customs Number	39199080
GTIN-13 / EAN	4031026219066
Labels per Row	3pcs.
Packaging 1 - Height (m)	0.15m
Packaging 1 - Length (m)	0.165m
Packaging 1 - Qty	7500
Packaging 1 - Type	bag
Packaging 1 - Volume (m³)	0.00223m³
Packaging 1 - Weight (kg)	0.750001kg
Packaging 1 - Width (m)	0.09m
Packaging 3 - Height (m)	0.24m
Packaging 3 - Length (m)	0.55m
Packaging 3 - Qty	90000
Packaging 3 - Type	carton
Packaging 3 - Volume (m³)	0.0515m³
Packaging 3 - Weight (kg)	9.5kg
Packaging 3 - Width (m)	0.39m
Packaging 4 - Height (m)	1.104m
Packaging 4 - Length (m)	1.2m
Packaging 4 - Qty	1440000
Packaging 4 - Type	pallet
Packaging 4 - Volume (m³)	1.06m³
Packaging 4 - Weight (kg)	173.0kg
Packaging 4 - Width (m)	0.8m
Storage Temperature	+21 °C
Storage conditions	50% relative humidity., The storage in the original packaging is recommended., Please avoid warehousing under impacts such as high humidity, heat and coldness.
