Label, white, thermal transfer print, 8.00x10.00mm, 10000
Nr. articol 596-12275
| TAG10-08TD5-892-WH
|
Detalii
- Suited to the slightly rough surfaces of IT ties and IMP/IT plates
- Adheres to rounded surfaces
- Rounded corners ensure better long term durability of adhesion
- White labels give excellent contrast
Solicitați acum oferta dumneavoastră individuală
Solicitați oferta
Mai multe produse în acest grup de produse:
| Application | These labels are specially tailored to the sizes used in the IT marking tie and IMP/IT plates. The flexible material sticks to the marking tie or tag, even on rounded surfaces. Print with HellermannTyton’s premium range of thermal transfer printers and ribbons for optimum print results. Using unique numbering, graphics or barcodes the labels give excellent asset identification possibilities. This solution produces professional marking of tubes, pipes, cables and other parts. |
| Application Method | The functionality and durability of the labels can be negatively affected if improperly processed or applied. All surfaces to be bonded must be clean, dry as well as free from dust and grease. Avoid touching the adhesive surface of the label as this could impair the application performance. |
| Chem. Material Properties | Good resistance against water, oils and most solvents. |
| Colour | White (WH) |
| Material | Type 892, Vinyl, white (892) |
| Mech. material properties | Permanent adhesive, suitable for critical surfaces like low energy surfaces. |
| PART DESCRIPTION | TAG10-08TD5-892-WH |
| Pack Cont. | 10000 |
| Package Content packed in | carton |
| Product Family | Helatag 892 |
| Product Group | Labels for IT ties and IMP plates, thermal transfer |
| Self adhesive (Yes/No) | Yes |
| Short Description | Labels for IT ties, IMP plates and tags 10x8 mm white |
| Type | TAG10-08TD5 |
Descărcare
| Adhesive | Acrylic |
| Curing Temperature | from 0 °C |
| ELV compliant (Article 4 - 2) | YES |
| Halogen-free | No |
| Hazardous Goods | No |
| Initial tack | 610g/cm² |
| Initial tack | ASTM D2979-71 |
| Operating Temperature | -40 °C to +80 °C |
| Pre-Printed | No |
| ROHS compliant | Yes |
| Recommended Ribbon Type | TT822OUT |
| Shear strength | 5h |
| Shear strength test method | ASTM D3654 |
| Shelf Life | Minimum 1 year upon receipt / maximal 2 years after production date. |
| Specifications |
|
| Country of Origin | DE |
| Customs Number | 39199080 |
| GTIN-13 / EAN | 4031026648477 |
| Labels per Row | 5pcs. |
| Packaging 1 - Height (m) | 0.15m |
| Packaging 1 - Length (m) | 0.09m |
| Packaging 1 - Qty | 10000 |
| Packaging 1 - Type | carton |
| Packaging 1 - Volume (m³) | 0.00223m³ |
| Packaging 1 - Weight (kg) | 0.7kg |
| Packaging 1 - Width (m) | 0.165m |
| Storage Temperature | +21 °C |
| Storage conditions | 50% relative humidity., The storage in the original packaging is recommended., Please avoid warehousing under impacts such as high humidity, heat and coldness. |
