Label, silver, thermal transfer print, 35.00x70.00mm, 500pcs.
Nr. articol 596-01902 | TAG70-35TDK1-1221-SR Detalii

  • Cost-effective replacement for engraved plastic plates, no need for additional label holder
  • High performance adhesive and compressible foam backing ensures optimal adhesion to uneven surfaces if required
  • Rounded corners ensure better long term durability of adhesion
  • Print high contrast text and barcodes
arată mai mult

Solicitați acum oferta dumneavoastră individuală

Application Panel labels are durable adhesive labels especially made from a thick material that is designed to replace traditional engraved plastic plates. The silver colour is suited to industrial control panels, switchgear, data racks and general equipment labelling. Create crisp and clear professional looking labels by printing with HellermannTyton thermal transfer printers and ribbons. Simple label design creation is easily achieved using TagPrint Pro.
Application Method The functionality and durability of the labels can be negatively affected if improperly processed or applied. All surfaces to be bonded must be clean, dry as well as free from dust and grease. Avoid touching the adhesive surface of the label as this could impair the application performance.
Chem. Material Properties Excellent resistance to ageing and weathering. Extensive resistance to the influence of chemicals and solvents.
Colour Silver (SR)
Colour Marking Field Silver (SR)
Material Type 1221, Polyester, silver (1221)
Mech. material properties Permanent adhesive with an elastic foam carrier.
PART DESCRIPTION TAG70-35TDK1-1221-SR
Pack Cont. 500pcs.
Package Content packed in reel
Product Family Helatag 1221
Product Group Panel plate labels, thermal transfer
Self adhesive (Yes/No) Yes
Short Description Control Panel Marking for Thermal Transfer Printing silver 90x45 mm reel = 500 pc.
Type TAG70-35TDK1
Height (H) 35.00mm
Print Method thermal transfer print
Print Method (Alternative) laser beam print
Thickness (T) 50µm
Thickness of Foil 50
Thickness of foil test method FINAT FTM 12
VR 38.00mm
Weight/Unit 0.00166kg
Width (W) 70.00mm
Width of Liner (WL) 76.00mm
Adhesive Acrylic
Curing Temperature from +10 °C
ELV compliant (Article 4 - 2) YES
Halogen-free No
Hazardous Goods No
Operating Temperature -40 °C to +90 °C
Peel strength 45 N/25mm
Peel strength test method DIN EN 1939
Pre-Printed No
ROHS compliant Yes
Recommended Ribbon Type TT122OUT, TT822OUT
Shear strength test method DIN EN 1943
Shelf Life Minimum 1 year upon receipt / maximal 2 years after production date.
Specifications
UV-Stabilised Yes
Country of Origin DK
Customs Number 39199080
GTIN-13 / EAN 4031026622620
Labels per Row 1pc.
Packaging 1 - Height (m) 0.115m
Packaging 1 - Length (m) 0.17m
Packaging 1 - Qty 500
Packaging 1 - Type carton
Packaging 1 - Volume (m³) 0.00332
Packaging 1 - Weight (kg) 0.83kg
Packaging 1 - Width (m) 0.17m
Storage Temperature +21 °C
Storage conditions 50% relative humidity., The storage in the original packaging is recommended., Please avoid warehousing under impacts such as high humidity, heat and coldness.
ETIM 7.0 Key EC001288
ETIM 8.0 Key EC001288
ETIM 9.0 Key EC001288
UNSPSC Key 39121702
