RFID transponder, 869 MHz (UHF), bolt-on, ∅50.00mm, H=3.50mm, black, 250pcs.
Nr. articol 556-00809 | RFID HARDTAG DISC-PPA-BK | Detalii

Identification element with integrated RFID transponder according to international standards
Rewritable memory
Made of very resilient carrier material
Mounting holes for attachment using bolts, screws, nails or rivets
Can be attached or embedded with the help of adhesives
Clear identification of objects and / or locations through unique numbering systems
Faster, more secure and error-free data management
Robust and durable
Relatively large range
Bulk detection of up to 500 transponders per second is possible thanks to the UHF frequency (depending on the infrastructure)

Solicitați acum oferta dumneavoastră individuală

Solicitați oferta

Găsiți un distribuitor în apropierea dumneavoastră

Mai multe produse în acest grup de produse:

Application	The universally applicable identification element RFID HARDTAG DISC PPA 50 is ideally suitable for the identification of objects and places indoors and outdoors due to their innovative design. Due to their robustness, the marking element can bis fixed permanently in a durable way to many objects and places. RFID elements of the HardLine product group are ideally suited for the clear identification of pallets or containers. The robust design allows those identification elements to withstand harsh conditions and rough treatment. An application would be the labelling of disposal bins like garbage cans, garbage cans and garbage containers.
Colour	Black (BK)
Fixation Method	bolt-on
Material	Polyphthalamide (PPA)
PART DESCRIPTION	RFID HARDTAG DISC-PPA-BK
Pack Cont.	250pcs.
Package Content packed in	bag
Product Family	HardLine – Ultra high frequency (UHF), bolt-on, blank
Product Group	Hard tags with RFID transponder
Short Description	RFID identification element diameter=50 mm, 869 MHz (UHF), PPA, black
Type	RFID HARDTAG DISC


Diameter (D)	50.00mm
Frequency	869 MHz (UHF)
Height (H)	3.50mm
Memory	User memory: 640 bits, EPC: 256 bits, TID: 112 bits
Weight/Unit	0.011kg
for Hole ∅ (FH)	5.2 mm

CE Certification	Yes
Data Retention	20 years
ELV compliant (Article 4 - 2)	YES
Halogen-free	No
Hazardous Goods	No
IP-Rating	IP68, IP69k
Operating Temperature	-40 °C to +85 °C
ROHS compliant	Yes
Radio protocol	ISO 18000-6C, EPC Gen2
Resistance to	Water: 100h (at room temperature), Salt mist: 100h (at room temperature), Fuel B: 100h (at room temperature), Petroleum: 100h (at room temperature), Mineral and vegetable oils: 100h (at room temperature)
Specifications
Specifications	IEC 62262: IK08, IEC 68-2-29, IEC 68-2-6
Tamper proof	No
Type of RFID chip	NXP Ucode G2iM+
Write endurance	100000 cycles
