Cable tie inside serrated, 190x3.5mm, ∅1.5-50.0mm, natural, 100pcs.
Art.-No. 111-01724 | T30L-PP-NA |  Details

The Allrounder: T-Series cable ties can be used for almost any type of application.

    • Available in a wide range of materials and sizes
    • High tensile strength with very low insertion force
    • Only high quality plastic is used meeting recycling targets
    • Inside serrated cable ties for a strong hold onto bundles
    • Ergonomic bent tail offers quick and simple installation
    • Easy application either manually or with an application tool
    Show more
    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads e-Learning
    Application T-Series cable ties for bundling and securing of cables, pipes and hoses. These cable ties can be used for nearly all kind of applications.
    Colour Natural (NA)
    Identification Plate Position none
    Material Polypropylene (PP)
    PART DESCRIPTION T30L-PP-NA
    Pack Content 100pcs.
    Package Content packed in bag
    Product Group Cable Ties inside serrated
    Releasable Closure (Yes/No) No
    Tie Closure plastic pawl
    Type T30L
    Variant Inside Serrated
    Bundle Diameter max (metric) 50.0mm
    Bundle ∅ min. 1.5mm
    Length (L) 190mm
    Min.Tensile Strength 105N
    Width (W) 3.5mm
    ELV compliant (Article 4 - 2) YES
    Hazardous Goods No
    ROHS compliant Yes
    Specifications
    UV-Stabilised No
    GTIN-13 / EAN 4031026522258
    Packaging 1 - Height (m) 0.03m
    Packaging 1 - Length (m) 0.243m
    Packaging 1 - Qty 100
    Packaging 1 - Type bag
    Packaging 1 - Volume (m³) 0.00103m³
    Packaging 1 - Weight (kg) 0.110001kg
    Packaging 1 - Width (m) 0.141m
    Packaging 3 - Height (m) 0.192m
    Packaging 3 - Length (m) 0.586m
    Packaging 3 - Qty 8000
    Packaging 3 - Type box
    Packaging 3 - Volume (m³) 0.0439m³
    Packaging 3 - Weight (kg) 9.602kg
    Packaging 3 - Width (m) 0.39m
    Packaging 4 - Height (m) 1.28m
    Packaging 4 - Length (m) 1.2m
    Packaging 4 - Qty 160000
    Packaging 4 - Type pallet
    Packaging 4 - Volume (m³) 1.229m³
    Packaging 4 - Weight (kg) 213.04kg
    Packaging 4 - Width (m) 0.8m
    UNSPSC Key 39121703
