Fixing tie for hole (round), inside serrated, ∅3.0-20.0mm, black
Art.-No. 156-00597 | T18RFT6SDSET-PA66HS/PA66HIRHS-BK |  Details

These fir tree fixings can also be used in threaded, blind holes.

    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Application Tool MK3PNSP2, EVOcut, MK7P, MK10-SB, MK20, EVO7, EVO7SP, EVO7i, EVO7iSP
    Colour Black (BK)
    Content 1000 T18R + 1000 FT6SD
    Fixation Method Fir Tree
    Identification Plate Position none
    Material Polyamide 6.6, heat stabilised (PA66HS), Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
    PART DESCRIPTION T18RFT6SDSET-PA66HS/PA66HIRHS-BK
    Package Content packed in bag
    Releasable Closure (Yes/No) No
    Tie Closure plastic pawl
    Type T18RFT6SDSET
    Variant Inside Serrated
    Bundle Diameter max (metric) 20.0mm
    Bundle ∅ min. 3.0mm
    Hole Depth 20.0mm
    Length (L) 100mm
    Panel Thickness max. (imperial) 0.118"
    Panel Thickness min. (imperial) 0.0295"
    Width (W) 2.5mm
    for Hole ∅ (FH) 6.4 - 7.1 mm
    for Panel Thickness min - max 0.8 - 3 mm
    for Panel Thickness min - max 0 - 0.1 "
    ROHS compliant Yes
    Specifications
    GTIN-13 / EAN 4031026404578
    UNSPSC Key 39121702
    Cable holder Cable holder

    Cable holder

    Looking for a secure way to fasten cables or wires? Our plastic cable holders are easy to install and suitable for almost any application. Learn more...
