Fixing tie with pipe/tube holder, ∅4.0-45.0mm, black, 250pcs.
Art.-No. 156-01031 | T50LOC1A-PA66HIRHSUV-BK |  Details

    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Cable Tie Polyamide 6.6, high impact modified, heat and UV-stabilised (PA66HIRHSUV)
    Colour Black (BK)
    Fixation Method Omega Clip
    Foot Part Polyamide 6.6, high impact modified, heat and UV-stabilised (PA66HIRHSUV)
    Identification Plate Position none
    Key product features lockable, rotatable
    Material Polyamide 6.6, high impact modified, heat and UV-stabilised (PA66HIRHSUV)
    PART DESCRIPTION T50LOC1A-PA66HIRHSUV-BK
    Pack Content 250pcs.
    Package Content packed in bag
    Product Group 2-piece fixing ties with pipe clip
    Type T50LOC1A
    Attach to Diameter 0.16 - 0.39 "
    Attach to Ø 4.0 - 10.0
    Bundle Diameter max (metric) 45.0mm
    Bundle ∅ min. 4.0mm
    Length (L) 390.0mm
    Min.Tensile Strength 225N
    Width (W) 4.7mm
    Flammability UL 94 HB
    Operating Temperature -40 °C to +105 °C
    ROHS compliant Yes
    Specifications
    UL Listed (US and Canada) No
    UL Listed (US and Canada) No
    UL Recognized (US and Canada) No
    UL Recognized (US and Canada) No
    UV-Stabilised Yes
    GTIN-13 / EAN 4031026456362
    Packaging 3 - Type box
    UNSPSC Key 39121717
    Cable holder Cable holder

    Cable holder

    Looking for a secure way to fasten cables or wires? Our plastic cable holders are easy to install and suitable for almost any application. Learn more...

    Cable holder >
