19/11/2024

Fixing tie for hole (round), inside serrated, black, 4000Set
Art.-No. 156-00186 | T50RFT6LG1SDSET-PA66HS/PA66HIRHS-BK |  Details

These fir tree fixings can also be used in threaded, blind holes.

    Package size
    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Anti rotation (Yes / No) NO
    Colour Black (BK)
    Content 4000 T50R + 4000 FT6LG1SD
    Fixation Method Fir Tree
    Identification Plate Position none
    Material Polyamide 6.6, heat stabilised (PA66HS), Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
    No. of sides for tie attachment 2
    PART DESCRIPTION T50RFT6LG1SDSET-PA66HS/PA66HIRHS-BK
    Pack Content 4000Set
    Package Content packed in box
    Releasable Closure (Yes/No) No
    Tie Closure plastic pawl
    Type T50RFT6LG1SDSET
    Variant Inside Serrated
    Disc ∅ 16.0mm
    Fixing Hole Shape Circular
    Length (L) 202.0mm
    Length of Fir Tree 11.1mm
    for Hole ∅ (FH) 6.5 - 7.0 mm
    ELV compliant (Article 4 - 2) YES
    Hazardous Goods No
    Operating Temperature -40 °C to +105 °C
    ROHS compliant Yes
    Specifications
    GTIN-13 / EAN 4031026267326
    Packaging 3 - Height (m) 0.184m
    Packaging 3 - Length (m) 0.58m
    Packaging 3 - Qty 4000
    Packaging 3 - Type box
    Packaging 3 - Volume (m³) 0.0406m³
    Packaging 3 - Weight (kg) 7.916kg
    Packaging 3 - Width (m) 0.38m
    Packaging 4 - Height (m) 1.248m
    Packaging 4 - Length (m) 1.2m
    Packaging 4 - Qty 96000
    Packaging 4 - Type pallet
    Packaging 4 - Volume (m³) 1.198m³
    Packaging 4 - Weight (kg) 210.984kg
    Packaging 4 - Width (m) 0.8m
    UNSPSC Key 39121717
    Cable holder Cable holder

    Cable holder

    Looking for a secure way to fasten cables or wires? Our plastic cable holders are easy to install and suitable for almost any application. Learn more...
