07/11/2024

Fixing tie for hole (round), ∅35.0mm, natural/black, 4000pcs.
Art.-No. 156-03129 | T50S-KSFT9-SQ-PA66HS/PA66HIRHS-NA/BK |  Details

Being a two-piece assembly allows the tie head to be located in the most convenient position.

    • Pre-assembled 2-piece fixing tie with arrowhead foot part
    • Cable tie head can be moved after bundling
    • Easy to assemble without the need for a tool
    • Arrowhead simply locks into place
    • Disc adjusts tie for pressure from various directions and minimises access of dust and dirt
    Show more
    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Application Primarily designed for fixing cable harnesses in the automotive industry, their simplicity and ease of use has resulted in these parts being used in other industries, for example aviation, switch gear and white goods manufacturing.
    Colour Natural (NA), Black (BK)
    Fixation Method arrowhead
    Identification Plate Position none
    Material Polyamide 6.6, heat stabilised (PA66HS), Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
    PART DESCRIPTION T50S-KSFT9-SQ-PA66HS/PA66HIRHS-NA/BK
    Pack Content 4000pcs.
    Package Content packed in carton
    Product Family 2-piece fixing ties with arrowhead, with disc, for round holes
    Product Group 2-piece fixing ties with arrowhead, with disc
    Tie Closure plastic pawl
    Type T50S-KSFT9-SQ
    Bundle Diameter max (metric) 35.0mm
    Length (L) 160.0mm
    Min.Tensile Strength 225N
    Panel Thickness max. 0.7-1.0mm
    Thickness (T) 1.2mm
    Width (W) 4.6mm
    for Hole ∅ (FH) 9.0 mm
    for Panel Thickness min - max 0.7 - 1 mm
    ELV compliant (Article 4 - 2) YES
    Hazardous Goods No
    ROHS compliant Yes
    Specifications
    GTIN-13 / EAN 4031026652801
    Packaging 1 - Height (m) 0.075m
    Packaging 1 - Length (m) 0.385m
    Packaging 1 - Qty 500
    Packaging 1 - Type bag
    Packaging 1 - Volume (m³) 0.00852m³
    Packaging 1 - Weight (kg) 0.905001kg
    Packaging 1 - Width (m) 0.295m
    Packaging 3 - Qty 4000
    UNSPSC Key 39121717
