Fixing tie for stud, inside serrated, ∅2.5-31.0mm, black, 300pcs.
Art.-No. 156-00792 | T50SKL-PA66HS/PA66-BK |  Details

    • Pre-assembled with cable tie and weld stud mounting base
    • Quick and easy installation
    • Head rotates into perfect position for installation
    • 'Soft-push' design for tool-free installation
    • Mushroom-shaped SBH handles insulation or a sound-deadening blanket
    • SBS ideal for installation prior to attaching cable (i.e. no lateral tolerances required)
    • SB5 allow lateral tolerance for fixing point
    Show more
    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Application Primarily designed for use in the automotive industry, these parts can be used in a wide variety of applications where 5mm weld studs or 5mm ISO bolts are used and cables need to be bundled and secured
    Colour Black (BK)
    Fixation Method Weld Stud Fixing with metal inlay
    Identification Plate Position none
    Material Polyamide 6.6, heat stabilised (PA66HS), Polyamide 6.6 (PA66)
    PART DESCRIPTION T50SKL-PA66HS/PA66-BK
    Pack Content 300pcs.
    Package Content packed in bag
    Product Group 2-Piece Fixing Ties for Weld Studs
    Tie Closure plastic pawl
    Type T50SKL
    Variant Inside Serrated
    Bundle Diameter max (metric) 31.0mm
    Bundle ∅ min. 2.5mm
    Height (H) 1.2mm
    Height (H2) 15mm
    Length (L) 150.0mm
    Length (L2) 20mm
    Min Stud Length 14.2mm
    Min.Tensile Strength 225N
    Stud ∅ 5.0 mm
    Width (W) 4.6mm
    Width (W2) 20.7mm
    ROHS compliant Yes
    Specifications
    GTIN-13 / EAN 4031026430171
    UNSPSC Key 39121717
    Cable holder Cable holder

    Cable holder

    Looking for a secure way to fasten cables or wires? Our plastic cable holders are easy to install and suitable for almost any application. Learn more...
