22/11/2024

Cable tie mount, Wmax=7.6mm, black, 100pcs.
Art.-No. 151-04422 | LOKS10J-PA66HSW-BK |  Details

    Add to watchlist
    Downloads Datasheet
    Application The LOK04 spacer is ideal whenever two or more cables are routed in parallel.
    Colour Black (BK)
    Fixation Method Wallmount Plug
    Key product features for multiple routing
    Material Polyamide 6.6, heat and UV-resistant (PA66HSW)
    PART DESCRIPTION LOKS10J-PA66HSW-BK
    Pack Cont. 100pcs.
    Package Content packed in bag
    Product Family LOK04
    Product Group Fixing base
    Type LOKS10J
    Length (L) 16mm
    Strap Width max. (G) 7.6mm
    Thickness (T) 6mm
    Width (W) 16mm
    Flammability UL 94 V2
    Operating Temperature -40 °C to +110 °C
    ROHS compliant Yes
    Specifications
    Country of Origin JP
    GTIN-13 / EAN 4944387129106
    ETIM 7.0 Key EC000449
    ETIM 8.0 Key EC000449
    ETIM 9.0 Key EC000449
    UNSPSC Key 39121717
