Cable tie mount for adhesive use, Wmax=2.7mm, black, 100pcs.
Art.-No. 151-02243 | MB2APT-A-PA66-BK |  Details

SolidTack Family with special adhesive.

    • MB mounts with homogeneous system of acrylic adhesive
    • Very good initial adhesion, increases with time
    • Innovative fixing solution for high and low energy surfaces
    • Protection foil with finger lift for easy peel off
    Add to watchlist
    Downloads Datasheet
    Application SolidTack MB Series mounts have a square design and are fairly common in areas like electrical cabinet, railway, aerospace, automotive and agriculture machinery. The premium self-adhesive bonds well on high and low-energy surfaces like plastics, metal, varnish or paint and is suitable for a wide range of applications.
    Colour Black (BK)
    Fixation Method Screw Mounting and Adhesive
    Material Polyamide 6.6 (PA66)
    PART DESCRIPTION MB2APT-A-PA66-BK
    Pack Cont. 100pcs.
    Package Content packed in bag
    Product Family SolidTack-Series MB
    Product Group Cable tie mounts with high performance adhesive
    Short Description Fixing parts with adhesive 13x13 black
    Type MB2APT-A
    Height (H) 4.1mm
    Length (L) 13.0mm
    Strap Width max. (G) 2.7mm
    Weight/Unit 0.000485kg
    Width (W) 13.0mm
    Adhesive Acrylate with base of acrylic foam
    ELV compliant (Article 4 - 2) YES
    Flammability UL 94 V2 (excluding adhesive)
    Halogen-free Yes
    Hazardous Goods No
    Operating Temperature -40 °C to +85 °C
    ROHS compliant Yes
    Specifications
    Country of Origin PL
    Customs Number 39269097
    GTIN-13 / EAN 4031026604077
    Packaging 1 - Height (m) 0.01m
    Packaging 1 - Length (m) 0.25m
    Packaging 1 - Qty 100
    Packaging 1 - Type bag
    Packaging 1 - Volume (m³) 0.00055m³
    Packaging 1 - Weight (kg) 0.05748kg
    Packaging 1 - Width (m) 0.22m
    Packaging 3 - Height (m) 0.368m
    Packaging 3 - Length (m) 0.584m
    Packaging 3 - Qty 25000
    Packaging 3 - Type box
    Packaging 3 - Volume (m³) 0.083m³
    Packaging 3 - Weight (kg) 14.965kg
    Packaging 3 - Width (m) 0.386m
    Packaging 4 - Height (m) 1.248m
    Packaging 4 - Length (m) 1.2m
    Packaging 4 - Qty 300000
    Packaging 4 - Type pallet
    Packaging 4 - Volume (m³) 1.198m³
    Packaging 4 - Weight (kg) 200.64kg
    Packaging 4 - Width (m) 0.8m
    ETIM 7.0 Key EC000449
    ETIM 8.0 Key EC000449
    ETIM 9.0 Key EC000449
    UNSPSC Key 39121717
