Cable tie inside serrated, 155x2.6mm, ∅2.0-40.0mm, black, 100pcs.
Art.-No. 109-00033 | Q18I-PA66-BK |  Details

Q-tie cable ties: choose from a wide product range in different sizes.

    This product is not available anymore.

    Alternative product available

    • Open lock head for quick and easy insertion
    • Integrated pre-locking function
    • More than 25 % faster in application
    • Inside serration for a strong hold around bundles
    • Easy application either manually or with a processing tool
    Show more
    Add to watchlist
    Downloads e-Learning
    Application Q-Series cable ties for bundling and securing cables, pipes a.d hoses. The innovative and effective cable ties enable a simple and quick installation.
    Colour Black (BK)
    Identification Plate Position none
    Material Polyamide 6.6 (PA66)
    PART DESCRIPTION Q18I-PA66-BK
    Pack Cont. 100pcs.
    Package Content packed in bag
    Product Family Q-ties
    Product Group Cable Ties with open head
    Releasable Closure (Yes/No) No
    Short Description Cable Tie with open head 155x2.6 black
    Tie Closure plastic pawl
    Type Q18I
    Variant Inside Serrated
    Bundle Diameter max (metric) 40.0mm
    Bundle ∅ 2.0-40.0mm
    Bundle ∅ min. 2.0mm
    Length (L) 155mm
    Min.Tensile Strength 80N
    Thickness (T) 1.0mm
    Weight/Unit 0.0003kg
    Width (W) 2.6mm
    ELV compliant (Article 4 - 2) YES
    Flammability UL 94 V2
    Halogen-free Yes
    Hazardous Goods No
    Operating Temperature -40 °C to +85 °C
    ROHS compliant Yes
    Specifications
    Specifications ANSI/UL 1565, ANSI/UL 62275, ANSI/UL 746B
    UL Listed (US and Canada) Yes
    UL Listed (US and Canada) Yes
    UL OCD link Link
    UL Recognized (US and Canada) No
    UL Recognized (US and Canada) No
    UL-File Number E65344
    Country of Origin ZA
    Customs Number 39269097
    GTIN-13 / EAN 4031026411873
    Packaging 1 - Height (m) 0.025m
    Packaging 1 - Length (m) 0.255m
    Packaging 1 - Qty 100
    Packaging 1 - Type bag
    Packaging 1 - Volume (m³) 0.00089m³
    Packaging 1 - Weight (kg) 0.030001kg
    Packaging 1 - Width (m) 0.14m
    Packaging 3 - Height (m) 0.27m
    Packaging 3 - Length (m) 0.59m
    Packaging 3 - Qty 25000
    Packaging 3 - Type carton
    Packaging 3 - Volume (m³) 0.0621m³
    Packaging 3 - Weight (kg) 8.33025kg
    Packaging 3 - Width (m) 0.39m
    Packaging 4 - Height (m) 1.224m
    Packaging 4 - Length (m) 1.2m
    Packaging 4 - Qty 400000
    Packaging 4 - Type pallet
    Packaging 4 - Volume (m³) 1.175m³
    Packaging 4 - Weight (kg) 154.28kg
    Packaging 4 - Width (m) 0.8m
    ETIM 7.0 Key EC000046
    ETIM 8.0 Key EC000046
    ETIM 9.0 Key EC000046
    UNSPSC Key 39121703
