Cable tie inside serrated, 565.3x12.4mm, ∅12.0-150.0mm, black, 25pcs.
Art.-No. 111-25001 | T250M-PA66-BK |  Details

Heavy duty T-Series cable ties feature inside serrations to provide a positive hold on wire and cable bundles.

    • Available in a wide range of materials and sizes
    • High tensile strength with very low insertion force
    • Only high quality plastic is used meeting recycling targets
    • Inside serrated cable ties for a strong hold onto bundles
    • Ergonomic bent tail offers quick and simple installation
    • Easy application either manually or with an application tool
    Show more
    Add to watchlist
    Downloads Datasheet e-Learning
    Application T-Series cable ties for bundling and securing of cables, pipes and hoses. These cable ties can be used for nearly all kind of applications.
    Application Method Quick, simple fixing by hand or with HellermannTyton tensioning tools
    Colour Black (BK)
    Identification Plate Position none
    Material Polyamide 6.6 (PA66)
    PART DESCRIPTION T250M-PA66-BK
    Pack Cont. 25pcs.
    Package Content packed in bag
    Product Family T-Series in PA66 black
    Product Group Cable Ties Polyamide 6.6 standard
    Releasable Closure (Yes/No) No
    Short Description Cable Tie 565x12.5 black
    Tie Closure plastic pawl
    Type T250M
    Variant Inside Serrated
    Bundle Diameter max (metric) 150.0mm
    Bundle ∅ 12.0-150.0mm
    Bundle ∅ min. 12.0mm
    Length (L) 565.3mm
    Min.Tensile Strength 1115N
    Thickness (T) 1.9mm
    Weight/Unit 0.015755kg
    Width (W) 12.4mm
    CE Certification Yes
    CSA Certified No
    ELV compliant (Article 4 - 2) YES
    Flammability UL 94 V2
    Halogen-free Yes
    Hazardous Goods No
    Operating Temperature -40 °C to +85 °C
    ROHS compliant Yes
    Specifications
    Specifications ANSI/UL 1565, ANSI/UL 62275, ANSI/UL 746B
    UL Listed (US and Canada) No
    UL Listed (US and Canada) No
    UL Recognized (US and Canada) Yes
    UL Recognized (US and Canada) Yes
    UL Type 11
    UL-File Number E64139
    UV-Stabilised No
    Country of Origin MX
    Customs Number 39269097
    GTIN-13 / EAN 4031026312149
    Packaging 1 - Height (m) 0.048m
    Packaging 1 - Length (m) 0.585m
    Packaging 1 - Qty 25
    Packaging 1 - Type bag
    Packaging 1 - Volume (m³) 0.00393m³
    Packaging 1 - Weight (kg) 0.393876kg
    Packaging 1 - Width (m) 0.14m
    Packaging 3 - Height (m) 0.225425m
    Packaging 3 - Length (m) 0.84455m
    Packaging 3 - Qty 500
    Packaging 3 - Type box
    Packaging 3 - Volume (m³) 0.0447m³
    Packaging 3 - Weight (kg) 8.52752kg
    Packaging 3 - Width (m) 0.23495m
    Packaging 4 - Height (m) 1.269m
    Packaging 4 - Length (m) 1.2m
    Packaging 4 - Qty 7500
    Packaging 4 - Type pallet
    Packaging 4 - Volume (m³) 1.218m³
    Packaging 4 - Weight (kg) 148.913kg
    Packaging 4 - Width (m) 0.8m
    ETIM 7.0 Key EC000046
    ETIM 8.0 Key EC000046
    ETIM 9.0 Key EC000046
    UNSPSC Key 39121703
