Cable tie inside serrated, 153x3.5mm, ∅1.5-37.0mm, transparent, 100pcs.
Art.-No. 111-00884 | T40S-PA11-CL |  Details

The Allrounder: T-Series cable ties can be used for almost any type of application.

    • Available in a wide range of materials and sizes
    • High tensile strength with very low insertion force
    • Only high quality plastic is used meeting recycling targets
    • Inside serrated cable ties for a strong hold onto bundles
    • Ergonomic bent tail offers quick and simple installation
    • Easy application either manually or with an application tool
    Show more
    Add to watchlist
    Downloads Datasheet e-Learning
    Application T-Series cable ties for bundling and securing of cables, pipes and hoses. These cable ties can be used for nearly all kind of applications.
    Application Method Quick, simple fixing by hand or with HellermannTyton tensioning tools
    Colour Translucent (TT)
    Identification Plate Position none
    Material Polyamide 11 (PA11)
    PART DESCRIPTION T40S-PA11-CL
    Pack Cont. 100pcs.
    Package Content packed in bag
    Product Group Cable Ties inside serrated
    Releasable Closure (Yes/No) No
    Type T40S
    Variant Inside Serrated
    Bundle Diameter max (metric) 37.0mm
    Bundle ∅ 1.5-37.0mm
    Bundle ∅ min. 1.5mm
    Cable Tie Head Height (metric) 4.4mm
    Length (L) 153mm
    Min.Tensile Strength 130N
    Thickness (T) 1.2mm
    Weight/Unit 0.0007kg
    Width (W) 3.5mm
    CE Certification No
    CSA Certified No
    ELV compliant (Article 4 - 2) YES
    Flammability UL 94 V2
    Halogen-free Yes
    Hazardous Goods No
    Operating Temperature -40 °C to +105 °C
    ROHS compliant Yes
    Specifications
    Country of Origin JP
    Customs Number 39269097
    GTIN-13 / EAN 4944387950939
    Packaging 1 - Height (m) 0.02m
    Packaging 1 - Length (m) 0.23m
    Packaging 1 - Qty 100
    Packaging 1 - Type bag
    Packaging 1 - Volume (m³) 0.0006m³
    Packaging 1 - Weight (kg) 0.070001kg
    Packaging 1 - Width (m) 0.13m
    Packaging 3 - Height (m) 0.2m
    Packaging 3 - Length (m) 0.505m
    Packaging 3 - Qty 10000
    Packaging 3 - Type box
    Packaging 3 - Volume (m³) 0.0374m³
    Packaging 3 - Weight (kg) 7.3201kg
    Packaging 3 - Width (m) 0.37m
    Packaging 4 - Height (m) 1.144m
    Packaging 4 - Length (m) 1.2m
    Packaging 4 - Qty 200000
    Packaging 4 - Type pallet
    Packaging 4 - Volume (m³) 1.098m³
    Packaging 4 - Weight (kg) 167.4kg
    Packaging 4 - Width (m) 0.8m
    ETIM 7.0 Key EC000046
    ETIM 8.0 Key EC000046
    ETIM 9.0 Key EC000046
    UNSPSC Key 39121703
