For hard, smooth surface applications, we recommend the use of our LFPC protective channels.

Stainless steel cable tie, ball bearing lock, 681.0x7.9mm, ∅25.0-203.0mm, red, 50pcs.
Art.-No. 111-02404 | MBT27HFCR-SS316L-RD |  Details

Stainless steel cable ties, coated, MBT_SFC, MBT_HFC.

    • Fully coated MBT, made from type 316 stainless steel with polyester coating
    • Non-releasable locking feature
    • Coated cable tie with smooth edges
    • Comfortable handling and installation
    • Eliminates contact corrosion between dissimilar materials during application
    Show more
    Add to watchlist
    Downloads Datasheet
    Application Stainless Steel cable ties with poyester coating provide a comfortable installation, especially when using outside at low temperatures. These products are chosen when a high tensile strength is demanded and a sensitive harness requires a carefully bundling.
    Colour Red (RD)
    Identification Plate Position none
    Internet Customer Notice For hard, smooth surface applications, we recommend the use of our LFPC protective channels.
    Key product features vibration absorbing
    Material Stainless Steel (SS316L)
    PART DESCRIPTION MBT27HFCR-SS316L-RD
    Pack Cont. 50pcs.
    Package Content packed in bag
    Product Family MBT-FC-Series
    Product Group Cable Ties with Ball-Lock and Coating
    Releasable Closure (Yes/No) No
    Tie Closure ball bearing lock
    Type MBT27HFCR
    Variant Not Serrated
    Bundle Diameter max (metric) 203.0mm
    Bundle ∅ 25.0-203.0mm
    Bundle ∅ min. 25.0mm
    Length (L) 681.0mm
    Min.Tensile Strength 1020N
    Width (W) 7.9mm
    Flammability non-burning (except coating)
    Limited Fire Hazard Yes
    Operating Temperature -80 °C to +538 °C
    Operating Temperature Coating -50 °C to +150 °C
    ROHS compliant Yes
    Specifications
    Country of Origin GB
    GTIN-13 / EAN 4031026604466
    ETIM 7.0 Key EC000046
    ETIM 8.0 Key EC000046
    ETIM 9.0 Key EC000046
    UNSPSC Key 39121703
