23/12/2024

Fixing tie with pipe/tube holder, ∅4.0-31.0mm, black, 500pcs.
Art.-No. 156-00689 | T30ROC1A-PA66HS/PA66HIRHS-BK |  Details

Bundle can rotate to any orientation, allowing routing in any direction regardless of mounting point.

    • For post-installation of additional cables for preassembled cable looms
    • Variety of twist angles and even different loop directions provide flexibility for cable routing
    • Additional cable tie dimensions are available
    Add to watchlist
    Downloads Datasheet
    Colour Black (BK)
    Fixation Method Omega Clip
    Identification Plate Position none
    Material Polyamide 6.6, heat stabilised (PA66HS), Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
    PART DESCRIPTION T30ROC1A-PA66HS/PA66HIRHS-BK
    Pack Cont. 500pcs.
    Package Content packed in bag
    Product Group 2-piece fixing ties with pipe clip
    Type T30ROC1A
    Attach to Ø 4.0 - 10.0
    Bundle Diameter max (metric) 31.0mm
    Bundle ∅ 4.0-31.0mm
    Bundle ∅ min. 4.0mm
    Length (L) 150mm
    Min.Tensile Strength 135N
    Thickness (T) 1.1mm
    Width (W) 3.6mm
    Flammability UL 94 HB
    Operating Temperature -40 °C to +105 °C
    ROHS compliant Yes
    Specifications
    Country of Origin CN
    GTIN-13 / EAN 4031026426280
    ETIM 7.0 Key EC000046
    ETIM 8.0 Key EC000046
    ETIM 9.0 Key EC000046
    UNSPSC Key 39121702
    Show all
