14/11/2024

Fixing tie with pipe/tube holder, ∅4.0-30.0mm, black, 500pcs.
Art.-No. 156-01390 | T30ROC1B-PA6HS/PA66HIRHS-BK |  Details

    Add to watchlist
    Downloads Datasheet
    Application Tool MK3PNSP2, EVOcut, MK7P, MK10-SB, MK20, EVO7, EVO7SP, EVO7i, EVO7iSP
    Cable Tie Polyamide 6.6, heat stabilised (PA66HS)
    Colour Black (BK)
    Fixation Method Omega Clip
    Foot Part Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
    Identification Plate Position none
    Key product features rotatable, for multiple routing, removable
    Material Polyamide 6, heat stabilised (PA6HS), Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
    PART DESCRIPTION T30ROC1B-PA6HS/PA66HIRHS-BK
    Pack Cont. 500pcs.
    Package Content packed in bag
    Product Group 2-piece fixing ties with pipe clip
    Type T30ROC1B
    Attach to Ø 4.0 - 10.0
    Bundle Diameter max (metric) 30.0mm
    Bundle ∅ 4.0-30.0mm
    Bundle ∅ min. 4.0mm
    Length (L) 148mm
    Min.Tensile Strength 135N
    Thickness (T) 1.1mm
    Width (W) 3.6mm
    ROHS compliant Yes
    Specifications
    Country of Origin CN
    GTIN-13 / EAN 4031026502106
    ETIM 7.0 Key EC000046
    ETIM 8.0 Key EC000046
    ETIM 9.0 Key EC000046
    UNSPSC Key 39121702
    Show all
